Specification(Business)
Model Dimension Resolution
TFTLCD17.1" 1280*1024
MP176 Color Resolution Contrast Radio
16.2M 500 1
Brightness Base dimension Outline dimension
300CD/m2 W*L*H(197*222*146) W*T*H(403*72*330)
I/O Connection
VGA port dB-15 port
Controller USB/COM (Optional)
DC Adapter DC12V\5A
Circumstance Condition
Operation Temperature -10 ~ 35degree
Store Temperature -20 ~ 60degree
Optional Fittings
Customer Display Optional
Magnetic Card Reader Optional
Others
Installing ways Hanging, Desktop VESA(Wall mount)
Power supply 110V-240VAC
Touch Screen MapleTouch 5-wire Resistive Touch screen(Hitting life: More than 35 million times for each point)
Product Certification FCC, CE
Standard Collocations
Mainboard Intel 945GM (Stable performance, superior quantity industrial motherboard)
CPU Celeron M 1.6G
Memory DDRII 1G
HDD SSD 16G
Audio Interface AC97 Audio (one sound input, one sound output)
Network Interface 10/100Mbps high speed Ethernet network (wireless network card optional)
USB port 4 units or more
RS232 Port 2 units or more
LPT Port 1 units
O/S Support Windows system, CE. Linux, ME, NT, etc
Guangzhou yulian electronic technology Co., Ltd. is the mainly professional manufacturer in producing mapletouch POS terminals, industrial control systems and multifunction inquiry touch kiosks in China. We have been an innovative and creative force in the development and manufacturing of high quality, high performance systems since 2000. Now our products have obtained the certificates of ISO9001: 2000, CE, FCC, CCC, CB, ROSH and widely applied to many fields.
