| Supplier: | Shijiazhuang Tilin Technology Co., Ltd. |
|---|---|
| Price: | US $ 0.258/Meter |
| Min Order: | 1000/Meter |
| Quantity:: | |
| Trade Terms: | FOB,CFR,CIF |
|
|
| Prod Model: | PPR 3 |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Color: | White, Gray, Green |
| Length: | 4 Meters , 6 Meters |
| Sizes: | 16mm To160mm |
| Material: | PPR |
1) Standard: German DIN 8077/8078
2) Colors: white, gray, green, Dimensions:16 - 160m
4) customers' logo are accepted
Features:
Material:Good PP resi(HYOSUNG R200P,Korea)and brass inserts
Pressure Rating: 2.5MPa
Standard: ISO 15874: 2003, DIN8077-8078
Production temperature: -40 - +95C
Certification: ISO9001, ISO14001, AENOR.
Color:Green,White,Grey etc.
Size: 16-160 mm
Applications:
cold or hot water supply, heating system including flooring heating, wall heating and radiant, central air conditioning and industrial liquids transportation.
Advantages:
High temperature resistance: the maximum sustained working temperature is up to 70 degrees, the maximum transient temperature is up to 95 degrees
Heat preservation: low thermal conductivity result in preserving heat
Non-toxic: no heavy metal additives, would not be covered with dirt or contaminated by bacterium
Lower installation costs: light weight and ease of installation can reduce installation costs
Higher flow capacity: smooth interior walls result in low pressure loss and high volume.
|
|
PN 1.0MPa | PN 1.25MPa | PN 1.6MPa | PN 2.0MPa |
|
Outer Diameter dn(mm) |
Wall Thickness en (mm) |
Wall Thickness en(mm) |
Wall Thickness en(mm) |
Wall Thickness en(mm) |
| 20 | 2 | 2.3 | 2.8 | 3.4 |
| 25 | 2.3 | 2.8 | 3.5 | 4.2 |
| 32 | 2.9 | 3.6 | 4.4 | 5.4 |
| 40 | 3.7 | 4.5 | 5.5 | 6.7 |
| 50 | 4.6 | 5.6 | 6.9 | 8.3 |
| 63 | 5.8 | 7.1 | 8.6 | 10.5 |
| 75 | 6.8 | 8.4 | 10.1 | 12.5 |
| 90 | 8.2 | 10.1 | 12.3 | 15 |
| 110 | 10 | 12.3 | 15.1 | 18.3 |
| 160 | 14.6 | 17.9 | 21.9 | 26.6 |
