Product Specifications
| Prod Model: |
Steel Structure |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Structure: |
Truss or Gabled Frames |
| Floor: |
One or Two Floors |
| Crane: |
5t-20t |
| Earthquake Resistance: |
7-8 Grade |
| Max Wind Speed: |
by Local Weather Condition |
| Steel Structure: |
Prefab Steel Structure Warehouse Shed |
| Material: |
Steel Structure |
| Usage: |
Prefabricated Buildings |
| Certification: |
SGS |
Product Description
Pre-engineering steel structure Workshop building low cost
Specifications
1, Well designed and cheap
2, Different size and material
3, Easy to installation
4, Reusable with long use life
Technical information
1. Wind resistance: Grade 11(wind speed≤ 111.5km/h)
2. Earthquake resistance: Grade 8
3. Live load capacity of roofing: 0.5kn/m2
4. External and internal wall heat transmission coefficient: 0.35Kcal/m2hc
5. Live load of corridor is 2.0kn/ m2
6. We can design and the house according to customer's requirements
The detailed description
1. Light steel structure prefabricated house with color steel sandwich panel, it is easy to install and can be moved, also it can be reused for numerous times.
2. The structure is reliable, also it is waterproof, fireproof, moisture-proof and quake-proof.
3. The design of the prefab house can be multiple modle, we can make as your requested.
4. Flexible layout, beautiful appearance, and high space efficiency.
5. Easy assembly and disassembly: The house can be assembled and disassembled many times, used repeatedly.
6. It can be recycled, and cause little rubbish, so it is environmental protection.
Optional Wall Panels
Thicknesses: 50mm, 75mm, 100mm
|
Types of Steel Structure |
|
Type |
Basic Parameter |
Light steel structure
workshop |
roof type: single span slope roof |
(solid-web rigid
frame & with crane) |
uniform steel structural beam-column with crane,
roof frame is variable, slope roof, use high strenth bolt connection |
|
pillar space: |
6m~9m |
|
span: |
20m~30m |
|
cornice height: |
6m~9m |
|
grade of slope: |
1/20~1/10 |
|
crane loading: |
5mt~10mt crane quantity: 1~4/span |
|
roof type: |
double spans slope roof |
|
section steel : |
uniform cross section steel structural beam-column a
nd roof framed, with two cranes, slope roof, use high strenth bolt connection,
large span, slope of bedding plant save the indoor space,
supprting column is in the middle of spans |
|
pillar space: |
6m~7.5m |
|
span: |
32m~60m |
|
cornice height: |
4m~9m |
|
grade of slope: |
1/20~1/10 |
|
crane loading: |
5mt~10mt |
|
crane quantity: |
1~4/span
|
Foshan Shengbang Steel Structure Co., Ltd. (for short "SBS") is a fast developing enterprises integrating marketing, design, development, manufacturing and construction. It has been approved and certified by international ISO9001: 2008 quality management system, and SGS factory system. We have trained many highly qualified marketing and technical personnel as well on-site construction team during recent years' fast development. Being customer demand-oriented, SBS provides a full range of services with rational, scientific and effective solutions, as a practical, progressive, innovative & solidarity company.
Our company prefabricated house is a new type environmental friendly product that adopts steel structure as frames, employs various plates and panels as surrounding protection system, uses high strength bolts as component connection. The prefabricated house is mainly used as modular house, office, cleaning workshop, cold storage room, wide span workshop, warehouse, exhibition hall, stadiums, hangars, steel-structure supermarkets, high-rise steel constructions, logistics center, container house and so on. Our house has been sold well to Middle East, Africa, Southeast Asia, South America and other more than 30 countries and areas.
Foshan Shengbang Steel Structure Co., Ltd. Possesses professional large-scale steel structure production equipments and the automatic spraying production line, so we can satisfy the different customers demand. We takes "build your future" as mission and takes company growth as premise. The company has trained many high quality marketing personnel, professional technician and construction workers. We take the customers' demand as the guidances, then provide reasonable, scientific and effective solution for customers. We regard practical growth, innovation and group solidarity as our company spirit, so that we can offer all-round service to customers.
Foshan Shengbang Steel Structure Co., Ltd. Will cooperate sincerely with the customers and build better future under the principle of win-win cooperation.
