Precision CNC Machining Prototype / CNC Model (LW-02085)

Name: Precision CNC Machining Prototype / CNC Model (LW-02085)
Brand: china-manufacturer-directory.com
SKU: 740783565
Availability: InStock
Rating: 4.3 (143 reviews)

Supplier:	Lead Well Technology Co., Ltd.
Price:	US $ 350-550/Piece
Min Order:	1/Piece
Quantity::
Trade Terms:	FOB,CFR,CIF

Product Specifications

Prod Model:	LW-02085
Markets:	Mid East,Eastern Asia,Western Europe
Application:	Sports
Process Combination Type:	Single-Process Mode
Shaping Mode:	CNC Machining

Product Description

Vacuum clearner function prototype with CNC machining (LW-02070)
Specifications
1. The prototype is machined in a solid part without any split.
2. High Polish to keep the part very transparent.
3. Keep the accurate dimension according to the 3D data
4. Short Lead time, and good surface treating for CNC part.

The basic methodology for all current rapid prototyping techniques can be follows:
1. A CAD model is constructed, then converted to STP, IGS, X-T format. The resolution can be set to minimize stair stepping.
2. The RP machine processes the. STL file by creating sliced layers of the Model.
3. The first layer of the physical models is created. The model is then lowered by the thickness of the next layer, and the process is repeated until completion of Model.
4. The model and any supports are removed. The surface of the model is then finished and cleaned.
3D Printing Technology is a new technology, which offers customers an accurate and fast process in obtaining coloured prototype
3D Printing is suitable for evaluating the physical form, aesthetics and function of a design.

CNC Prototypes Manufacturing

CNC Prototypes Advantage
1. Machine many materials that is economically available to choosing.
2. Typical accuracy is +/-0.1mm. Ability to hold tight tolerances and high precision.
3. The cost be cheaper than even SLA, SLS, FDM rapid prototypes depending on the geometry.

Prototyping Solution	Material	Tolerance
Computer Numerical Control (CNC)	Any material that is commercially available in stock sizes. A wide variety of plastic and metal material options.ABS,PMMA,POM,PP,PU,PC,PA66,PMMA,PVC,PVE, aluminum Zinc alloy, copper, iron, steel.	+/- 0.005"
Fused Deposition Modeling (FDM)	production-quality ABS, ABS-M30 Polycarbonate PC-ABS PC-ISOULTEM, & PPSF	+/- 0.002"
Low Volume production(Silicone Mould /vacuum casting)	ABS,PP,PC,PMMA,POM,Nylon ,PU and so on	+/- 0.003"
Precision low volume production(injection molding)	ABS,PMMA,POM,PP,PU,PC,PA66,PMMA,PVC,PVE,	+/- 0.001"
Metal prototypes(CNC,EDM,Drilling, Milling)	Aluminum, Stainless Steel, Carbon Steel, 17-7 PH, Brass, Phosphor Bronze, Copper, Nickel Alloys, Beryllium Copper,metal and plastic rapid prototype	+/-0.005"
Stereolithography (SLA)	Technician's Choice, Semi-Flexible, PE-Like Durable, PP-Like,ABS-Like High-Impact ABS-Like Rigid, PC-Like High-Temp ABS-Like High Resolution	+/- 0.002"
Selective Laser Sintering (SLS)	Nylon, Glass-Filled Nylon, Flame Retardant Nylon and Durable Nylon.	+/- 0.005" Layer Thickness: 0. 004".
3D Printing	ABS or PLA. Fast to print the model within 1~2hours	+/- 0.003"
Surface Treatment:	- Can be painted in any color with silk LOGO - Semi-transparent & 100% transparent - Laser engraving marks on surfaces - Anodizing - Electroplating - Painting - Chrome plating - Powder coating (Sand blasted)	Proper for plastic and metal parts

Lead Well Technology Co., Ltd, is a precise and professional manufacturer which specialized in plastic and metal rapid prototyping, and are involved in product design, 3D scan, SLA rapid prototyping, CNC prototyping, sheet metal prototyping, Small batch prototype casting by silicone mold, surface treating including painting, silk printing, Electronic-plated. Our company had a plenty of advanced equipments such as the SLA machine, Large-sized computerized numberial control processing center precise carving machines, vacuum casting machines, CNC punching machine, folding machine, and laser engraving machine etc.

With the Effective experienced engineers, Quick Response to the quote Requests, Quality Parts & Prototype Guaranteed, Fast Turnaround Delivery, Awesome Customer Service, The good reputation had already obtained from our overseas clients.

Our goal is to be your premier and right choice for CNC machining shop in China. If you have any inquiry or idea that you would like to quote, dont hesitated to contact us.
