Product Specifications
| Prod Model: |
CM200 |
| Markets: |
South America,Eastern Europe,Mid East,Eastern Asia |
| Type: |
Glass Cutting Machine |
| Control System: |
PLC |
Product Description
Application:
Multi-saw blade or single-saw blade precision cutting machine is mainly used for cutting prism ,optical glass, ceramic, crystal and other brittle materials.
Technical Data:
Size of table (length × width) 400 × 200mm
Max. distance from the table to the axis of saw spindle 270mm
Transverse movement of table 420mm
Longitudinal movement of table 200mm
Up and down movement of saw spindle 150mm
Diamond saw (OD × ID) 180 × 40
Table cutting feed speed (transverse) 8 -200mm/min
Table fast forward speed (transverse) 2000mm/min
Saw spindle speed 2000/ 4000rpm (two steps)
Dimension 2600 * 2700*1710mm
Weight 1000kg
FULAN OPTICS MACHINE Co., Ltd has entered into optics/ophthalmic industry since 1987, and has been specialized in manufacturing of precision optics machine, ophthalmic lens machine, mobile glass machine, optical equipment, ophthalmic instrument, diamond tool, etc.
A. Precision Optics Machine and Consumable.
1) Glass sawing machine, Cylindrical grinding machine, Centerless grinding machine.
2) Spherical(curve)/Plano generator, Optical/Mechanical centering machine.
3) High speed spherical/plane surface lapping & polishing machine.
4) Slow speed spherical/plane surface grinding & polishing machine.
5) Diamond sheet, diamond wheel, diamond pellet, polyarethane polishing pad, polishing powder.
B. Ophthalmic Lens Machine and Consumable.
1) Alloy blocker. Alloy deblocker. Center thickness gauge. Spherometer. Torometer.
2) Spherical/Toric generator. Toric Lap cutter.
3) Spherical/Toric fining & polishing machine.
4) Lap tool. Diamond tool. Metal Fining pad. Glass polishing pad. Polishing powder.
5) 65C/47C Blocking alloy. Surface protection tape. Fining pad. Polishing pad. Polishing compound.
C. Optical Equipments/ Instruments.
1) Patternless auto edger. Auto lens edger. Pattern marker. Layout blocker.
2) Auto lens groover. Lens drilling machine. Auto lens polisher (Buffer).
3) Hand lens edger. Ultrasonic cleaner. Frame heater/warmer.
4) Auto lensmeter. Lensmeter (Vertometer).
D. Ophthalmic Equipments/ Instruments.
1) Ophthalmic chairs&stands. Phoropter (Refractor, View tester). Digital refractor(Auto phoropter). Auto chart projector. Trial lens set. Digital pupilometer (PD meter).
2) Slit lamp. Auto refractometer&keratometer. Auto refractometer. Keratometer. Retinoscope. Ophthalmoscope. Non-contact tonometer. Applanation tonometer. Auto campimeter. A scan. A/B scan.
3) Operation microscope. Operation table. Micro ophthalmological surgical appliances.
