Product Specifications
| Prod Model: |
DLQ |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Name: |
Precision Filter |
| Material: |
304ss or 316L |
| Filter Bag Sectional Shape: |
Round Bag |
| Filter Length: |
10 "~ 40" |
| Cartridge Quantity: |
1 Core to 180 Cores |
| Filter Bag Environment: |
Room Temperature |
| Usage: |
Liquid Filter, Water Filter |
| Replace The Pressure: |
0.05MPa-0.07MPa |
| Vseal Materia: |
PTFE, Rubber |
| Application: |
Water Filter |
Product Description
Product Description
1um SUS304 0.6mpa Juice and Mineral Water Precision Filter
1. Characteristics
1, high filtration precision, uniform pore size filter.
2, small filtration resistance, flux, interception capability, long service life.
3, filter is clean and no second pollution to the filter media.
4, It also can filter acid, alkali and other chemical agents.
5, high-intensity, heat-resistant, deformation resistance.
6, low price, low running costs, easy to clean, filter can be replaced.
2. Application
1, Food industry: Fine filter of space water, mineral water, beverages, liquor clarification and filtration process.
2, Pharmaceutical industry: Sterile water, oral, infusion and injection water treatment.
3, Electronics industry: Water preparation semiconductors, instruments, picture tubes and other production plants, wash water filtration bar.
4, Chemical industry: Organic solvents, esters, alcohols, acids, alkalis and other chemicals, oils purification.
5, Oil industry: Oil field water injection preparation and so on.
6, Environmental protection, electroplating wastewater, printing waste, pharmaceutical waste and other industrial wastewater treatment.
7, Seawater, brackish water desalination water treatment, hotels, apartments water treatment.
8, Precision filter is often used as security filter for electrodialysis, ion exchange, security filters reverse osmosis devices.
3. How precision filter works
Precision Filter, also known as security filter. The shell is made of high quality stainless steel, filter using molded filter, The liquid went through filter under pressure, residue left on the filter, and the filtrate outflow through the filter can effectively remove impurities in the water, sediment and suspended solids, bacteria.
Molded filters are: Cloth, screen, filter, sintered filter tube, wound filter, melt-blown filter, micro-porous filter and multi-function filter.
Due to different filter, the filter pore size is not the same. Precision filter is between the sand filter (coarse) and a filter between ultra-filtration, filter pore size generally between 0.01-120um. For the same form of filter, it is divided into different models by their dimensions.
3. Parameter
Working pressure: 0.6 / 1.0 / 1.6Mpa
Body Material: Stainless steel (SUS304, SUS304L, SUS316, SUS316L).
Operating temperature: 5 ~ 40 º C (exceed 60 º C to be informed)
Design temperature: 5 º C -100 º C
Replace the pressure: 0.05Mpa-0.07MPA
Filter interface: Flat compression, plug-in
Cylinder and base connection mode: Quick opening, flanged
Filtration accuracy: 1μ M ~ 100μ M
Cartridge Quantity: 1 core to 180 cores
Filter Length: 10 "~ 40"
Seal type: O-ring or flat washer
Seal Material: PTFE, rubber.
Finish: Matte jet beads, mirror electrolytic polishing.
Sealing material: Nitrile rubber, silicone, Viton, standard configuration for the silicone seal.
Interface Type: GB, HG, DIN, ANSI, JIS standard flanges, dental mouth, clamps and so on.
Flange Standard: GB, HG, SH, HGJ, JB, ANSL, JIS and other standards.
Manufacturing, testing standard: GB150 standard, or user-specified criteria.
4. Composition
Precision filter is mainly composed by the filter housings, filter cartridges and other components, and the filter housings materials is mostly made of R304 stainless steel, if it's used in the acid and other special occasions, it will be made by R316 stainless steel. It an be divided into the flange and clamp, and flanged housing is mainly used in the occasion of larger flow filtration. The filter is mainly made by PP cotton, it can also be made by wound filter or activated carbon filter on some occasions. The number of filter may vary from 1 to dozens, primarily be determined from the water flow rate.
