Product Specifications
| Prod Model: |
ZM3196 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| OEM: |
Supply |
| Customer Ddesign: |
Supply |
| Package: |
Wooden Box |
| Delivery Time: |
60 Days |
Product Description
ZM3196 Process Control Trainer
1 Product Overview
1.1 Overview
This equipment's frame is made of industrial aluminum, it is equipped with stainless steel heating water tank, and it is equipped with various temperature probes and controlling instruments, so it is suitable for temperature measurement and control training.
1.2 Features
(1) This equipment's frame is made of aluminum and it is equipped with power box and storage cabinet.
(2) The stainless steel water tank has function of heat preservation and agitation, and there are various temperature probes for selection.
2. Training project introduction
Training project: the recognition of process control and detection device of hardware structure, the composition of control scheme, and the experiment of connection.
The experiment consists of four parts: Power box, controlled object, control instrument and hanging box module
Power box provide all kinds of power supply for the system, and provide 0-10V and 4-20mA signal; controlled Object are mainly composed of DC diaphragm pumps, DC heating tube, mixing machine, etc; control instruments are composed of some sensor: Temperature sensor , pressure sensor, flow rate sensor: Hanging box module are composed of certain units of Drive circuit unit, PLC and I/O module unit, the button lamp units, etc
System power branch divided into two road: one road consists of certain parts: 24 v DC drive pump, electric regulator, DC electromagnetic valve, flow meter and manual control valve; the other road consists of certain parts of DC motor not go by the regulator, but directly go by manual valve to the tank. System circuit diagram is shown in figure
3 Technical Specifications
(1) Input power: Two-phase three-wire, 220V±10% 50Hz
(2) Dimension: 1200mm×600mm×1600mm
(3) Heating power: 1.5KW, Power of agitator: 5W
(4) Heating water tank volume: 20L
(5) Weight: <120kg
(6) Operating conditions: Environment temperature -10ºC~+40ºC
