Product Specifications
| Prod Model: |
HL-QG-BT-C2 |
| Markets: |
North America,South America,Southeast Asia,Africa,Mid East,Eastern Asia |
| Size: |
Standard or Customized |
| Accessory: |
Customized |
| Fitting: |
Customized |
| Details: |
Customized |
| Frame: |
C-Frame, H-Frame or Pedestal (None) |
| Warranty: |
5 Years |
| Kind: |
Bench |
| Material: |
Steel |
| Color: |
Optional |
Product Description
HUILV labarotory furniture should be customized.
Work Top: The below options are available. All the lab worktops is chemical resistant, heat resistant, against solvent,
Acid and alkali resistant, scratch and impact cutting resistant. Monolithic smooth, non-glare finish.
Phenolic tops: 13/16/19/25mm thickness of Wilsonart Chemsurf chemical resistant laminate;
15/19/25mm thickness Belmax Lab grade phenolic resin laminate.
Epoxy Resin Tops: 13/16/19/25mm Durcon Epoxy Resin Worksurface.
16/19/25mm Siruike lab grade epoxy resin tops.
Ceramic tops: 20mm/30mm Ornices Ceramic Work Top.
Trespa tops: 13mm/15/19mm Trespa worktop.
Compact tops: 13mm.
Body & Cabinet: Drawer / Cupboard Cabinet/Hunging cabinet. Using 1.2 mm thick of cold-rolled steel sheet production.
The steel parts by acid washing, phosphating and static electrical spraying with epoxy resin powder for erosion resistance.
High temperature curing treatment. The acid-and alkali coorosio, abrasion, scratch and impacting ing.
3mm special welding edging. Customized size and style.
Optional Sink: International standard lab grade PP sink, epoxy sink, ceramic sink are available for option.
Reagent Rack: The main frame is made of 1.5mm thickness of cold-rolled steel plate. The adjustable shelve
Are made of 12mm thickness of reinforce glass with stainless steel tube for guardrail.
Electric Fitting: Sockets and power point all are optional for electric supply. According to customer specification.
Water Faucet: Cold & hot water outlet, two way water Outlet, three way water outlet are available.
Accessories: Pegboard, eyewash, gas outlet are should be used in the lab bench.
Hinge: 105/175 degree open type high quality hinge; 2.0mm thickness 304# stainless steel hinge;
Hydraulic hinge are available.
Handle: 304# Stainless steel handle; Embedded aluminum handle with epoxy coating, lines handle are available.
Slideway: Stainless steel self-closing three section slide rail, no noise. Hydraulic slideway are available.
Please be noted: All the specification and requirement should be customized.
Worktops |
16mm thick lab grade phenolick resin (black), most chemicla resistant |
Frame |
C frame, 40*60*1.5mm square steel tube with 75μm epoxy powder coating |
Dimension |
Length * 750 *850mm ( customized ) |
Cabinet body |
1.2mm thick cold-rolled with 75μm epoxy powder coating, most chemical resistant |
Door |
Double buckle fastening of inside and outside, filled with insulation material |
Drawer |
Cold-rolled steel sheets, with double levels of covers, with sound insulation material filled inside |
Hinge |
DTC175° high quality hinge |
Handle |
Embedded aluminum alloy handle |
Faucet |
Brass body with ceramic valve core coated with epoxy resin powder |
Sink |
High grade PP, most chemical resistant |
Socket |
Special lab Multi socket, double electric |
Guangdong Huilv Laboratory Equipment Scientific & Technological Co., Ltd. is a specialized manufacturer of modern lab furniture. We integrate consultation, production, installation, and after-sales service together.
We have attained ISO9001: 2000 and ISO14001: 2004 certifications. Our company mainly produces various kinds of laboratory furniture and devices.
Our company has been established for 10 years since 1999. We furnished high-quality products and excellent service based on newest design and modern production technology.
We have regarded the quality of products as the life of our company. At the same time, we have extended our sales network to other fields such as layout before sale, consultation and design, specialized installation, and regular feedback.
We focus on establishing a modern lab of safety, high-efficiency and personality for customers.
