| Supplier: | Guangzhou Haoyi Audio Co., Ltd. |
|---|---|
| Price: | Negotiable |
| Min Order: | 1 |
| Quantity:: | |
| Trade Terms: | Ex-work |
|
|
| Markets: | North America,Southeast Asia,Africa,Mid East,Eastern Asia,Western Europe |
|---|
| Items | SPA1.2 | SPA1.0 | SPA0.8 | SPA0.7 | SPA0.6 | |
| Features | 1,Reasonable Thermal And Construction Design | |||||
| 2,High Efficiency Aluminium Heat-sink | ||||||
| 3,Light Weight, 300watts/kg | ||||||
| 4,High Power Transistor Direct Contact to Heat-sink | ||||||
| 5, Double High Efficiency Switching Mode Power Supplyes | ||||||
| 6,Class H Linear Output Circuit | ||||||
| 7, MAX. 4 pcs High Performance DC Fans | ||||||
| Freq. Response (At 1 Watt) | 20Hz~20KHz,+/-0.5dB | |||||
| S/N Ratio, Unweighted | 89dB | 89dB | 89dB | 89dB | 89dB | |
| THD (At Half Rated Power) | 0.08% | 0.06% | ||||
| Damping Factor (8 ohm20-400Hz): | >450 | >350 | ||||
| Crosstalk(Below -3dB Rated Power) 20Hz-1KHz | 72dB | 70dB | ||||
| Gain (at max. Level,0.775V,+/-5%) | 39.7dB | 38.2dB | 39.7dB | 38.2dB | 36.0dB | |
| SlewRate(Below -3dB Rated Power) | 20V/uS | |||||
| Power Output | 8 ohm Dual | 1100W | 900W | 700W | 500W | 300W |
| 4 ohm Dual | 1900W | 1550W | 1050W | 750W | 450W | |
| 2 ohm Dual | 2400W | 2000W | 1000W | 500W | 300W | |
| 8 ohm Bridge | 3800W | 3100W | 2100W | 1500W | 900W | |
| 4 ohm Bridge | 4800W | 4000W | 2000W | 1000W | 600W | |
| Required AC Mains | 220Vac 50~60Hz | |||||
| Dissipation Power At Idle | <79W | <59W | ||||
| Controls | Power | On-Off, On Front Panel | ||||
| Level | -80dB~0dB, On Front Panel | |||||
| Mode | Stereo-Parallel-Bridge, On Rear Panel | |||||
| Sensitivity | 1.4V-1.0V-0.775V, On Rear Panel | |||||
| Ground Lift | On-Off, On Rear Panel | |||||
| 30Hz Low Cut | On-Off, on the rear panel | |||||
| Indicators | Power | Green LED, On Front Panel | ||||
| Signal | Green LED, On Front Panel | |||||
| Protection | Red LED, On Front Panel | |||||
| Clip | Red LED, On Front Panel | |||||
| Bridge | Orange LED, On Rear Panel | |||||
| Input/Output | Input Connects | XLR-F, XLR-M | ||||
| Input Impedance | 10KΩ Unbalanced, 20KΩ Balanced | |||||
| Output Connectors | Speakon | |||||
| Output DC Offset | 3mV | |||||
| Protection | Clip Limiter, Short Circuit, Thermal, DC Voltage, Soft Start, EMI Filter, Subsonic Signal, SSC, DRC,HF | |||||
| Construction | Material | Steel Chassis | ||||
| Cooling | Force-Cooling System, Two(Four for SH1100/900) Variable Speed Fans, One extra for PSU | |||||
| Unit Dimensions | 483*89*356.5mm | 483*89*456.5mm | ||||
| Packing Dimensions | 580*470*130mm | 580*570*130mm | ||||
| Net Weight | 15.00KG | 14.00KG | 10.00KG | 9.80KG | 9.00KG | |
| Shipping Weight | 16.80KG | 15.80KG | 11.50KG | 11.30KG | 10.50KG | |
| AC Fuse | T20A250Vac | T20A250Vac | T12A250Vac | T10A250Vac | T8A250Vac | |
| Accessories | User's Manual, Power Cord, | |||||
