Programmable LED Display

Name: Programmable LED Display
Brand: china-manufacturer-directory.com
SKU: 700552875
Availability: InStock
Rating: 4.5 (20 reviews)

Supplier:	Shenzhen Hangrand Technology Co., Ltd.
Price:	Negotiable
Min Order:	1/Square Meter
Quantity::
Trade Terms:	FOB

Product Specifications

Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Place Of Origin:	Guangdong, China (Mainland)
Brand Name:	Hangrand
Model Number:	Hg-Op10c
Pixels:	10mm
Service:	Service
Warranty:	2 Years
LED Chip:	CREE/Silan/Opto
Delivery:	10-15 Working Days
Payment:	T/T, L/C
Ingress Protection:	IP65
Usage:	Outdoor
Tube Chip Color:	Full Color
Display Function:	Video
Certification:	CE & RoHS

Product Description

Hangrand Corrosion-resistent, Strict Waterproof Test Outdoor LED Display

1, high quality tubes
2, stable performance
3, FP grade 94 CV0
4, UV proof
5, resistance of high and low temperature

Product Features

1. Color spots or picture shade will be removed through the adjustment of brightness and color by each independent pixel
2, adopted with self developed steel structure and special kits will be kept in good flatness and smoothness
3, strict water proof testing by IP65
4, according to environmental changes the brightness can be adjusted automatically for energy saving
5, special PVC kits are adopted to protect from corrosion according to coastal weather
6, according to environmental changes the brightness can be adjusted automatically for energy saving
7, auto power on/off, work unattended

LED Parameters

Module Specifications
1	Pixel Pitch	10mm
2	Display Resolution	32*32 dots
3	Pixel Configuration	1R1G1B
4	Driving method	Static constant current

Cabinet Specifications
1	Cabinet Resolution(dot)	128 pixels L x 128 pixels H
2	Size	1280mm x 1280mm
3	Weight/ Cabinet Depth	112kg/ 125mm
4	Material	Galvanized Steel

Screen Parameters
1	Real pixel pitch	10mm
2	Real pixel density	10000/m2
3	Virtual pixel density	10000*4/m2
4	Drive IC	MBI5026
5	Display colors	163841638416384 totally
6	Brightness	≥ 6500cd/m2
7	Grey level	Red, Green, Blue 16384 grade/Each
8	Viewing angle	Horizontal: ≥ 140° , Vertical: ≥ 60°
9	Best viewing distance	10m-300m
10	Valid viewing distance	< 350m
11	Frame frequency	≥ 60HZ
12	Refresh frequency	≥ 400HZ
13	Driving method	Static constant current
14	Brightness adjustment	Automatically or manually
15	Control method	Synchronized with PC
16	Display mode	640480-1024768
17	Visual input	VGA mapped /NTSC/PAL
18	Information transmission method	Synchronized and balanceable transmission
19	Communication cable	UTP Category 5/multi-mould optical fiber/monomode fiber
20	Scotoma rate	≤ 1/10000
21	Continuous operation time	≤ 48 hours
22	LED Lifespan	≥ 100, 000 hours
23	Assembly precision between PCB	≤ 1mm
24	Max. /Average power consumption	≤ 1100 w/m2/ ≤ 550 w/m2
25	Input voltage	AC 220V/110V /50 HZ+/-10%
26	Operation envionment	Temperature: -20° C~+50° C
27	Input signal	S-video, VGA, RGB, Composite video, SDI etc.
28	Ingress grade	IP65/IP54
29	Video display function	Varies of text, graphics, pictures, flashes, and any signals from TV, VCB, DVD, camera and scanner can be synchronized with PC, Support PAL/NTSC

Shenzhen Hangrand Technology Co., Ltd. is a Hi-Tech enterprise specializing in LED displays, LED & LED lighting products and LED decoration products. We are mainly engaged in the production of outdoor&indoor LED displays, LED bulbs, LED spotlights, ceiling lamps, LED tubes etc.
Our products have gained national patent (Patent NO: 0226570.8). We also have passed CCC, CE, RoHS, FCC and UL Certifications. Our products have been sold to Europe, American, Middle East, Africa and Australia.
Our company is located in the Hengguan Industrial Park in Pinghu, Shenzhen. Our factory covers more than 10000sqm and has 600 employees including 50 senior technicians. Our highly skilled staff members and excellent management persons have implemented a strict quality supervision and inspection system, which ensures that our products can achieve international standards. Our R&D Dept. Has strong capability of developing new items in accordance with customers' requirements. OEM and ODM orders are welcome. We strongly believe in the tenet of "innovation forever, which can lead to a bright future".
We are looking forward to building up good business relationships with all customers based on mutual benefits. You are welcome to visit us and contact us for more details.
