Product Specifications

Prod Model:	HX-PCBA-111
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Size:	122.23 X 145.32mm
Base Material:	FR-4
Mode Of Production:	DIP
Metal Coating:	Tin

Product Description

Services:
Design and product engineering
Bare PCB fabrication
Component procurement
Stock control and warehousing
Production
Quality control and test
Packaging and dispatch

Added benefits to using a turnkey solution:
Facilities marketing objectives
Reduces inventory
Cost-effective
Just-in-time (JIT) delivery

The following information is requested for this service:
Gerber files of the bare PC board
Dimensional specifications for non-standard components
Assembly drawing including any change notices
Final test procedures
In order to shorten the lead time, please advise us acceptable components for substitution.

Estimated order quantity:
If possible, please send prototype sample board to us for further reference. Other products from this supplier.

Item	Mass Production	Pilot Run Production
Item	Capacity	Capacity
Layer Counts	1L_18L, HDI	20-28 , HDI
Material	CME1,CME3,FR-4, High TG FR4 , Halogen-free FR4 , aluminium ,Ceramic(96% Alumina)
Material	Teflon,PTFE(F4B,F4BK), Rogers(4003,4350,5880) Taconic(TLX-8,TLX-9), Arlon(35N,85N)etc.
Material Mixed Laminate	4 layers -- 10 layers	12 layers
Material Mixed Laminate	FR4+Ro4350 , FR4+Aluminium , FR4+ FPC
Maximum Size	610mm X 1200mm	1200 - 2000MM
Board Outline Tolerance	±0.15mm	±0.10mm
Board Thickness	0.125mm--6.00mm	0.1mm--8.00mm
Thickness Tolerance ( t≥0.8mm)	± 8%	±5%
Thickness Tolerance( t<0.8mm)	±10%	±8%
Minimum Line / Space	0.10mm	0.075mm
Trace width Tolerance	15%-20%	10%
Minimum Drilling Hole (Mechanical)	0.2mm	0.15mm
Minimum laser hole	0.1mm	0.075mm
Hole Position/hole Tolerance	±0.05mm PTH:±0.076MM NPTH:±0.05mm
Mini hole ring (single	0.075MM	0.05MM
OutLayer Copper Thickness	17um--175um	175um--210um
InnerLayer Copper Thickness	17um--175um	175um--210um
Mini Solder Mask Bridge	0.05mm	0.025mm
Impedance Control Tolerance	±10%	±5%
Surface Finishing	HASL, Lead free HASL, Immersion gold, Immersion tin, Immersion Silver.
Surface Finishing	Plated gold , OSP, Carbon ink,
1-2L Lead-time	3-7 days	1-2 days
4- 8L Lead-time	7-10 days	2-7 days
10-18L Lead-time	10-15 days	4-9 days
20-28L Lead-time	15-20 days
Acceptable File Format	ALL Gerber Files,POWERPCB,PROTEL,PADS2000,CAD,AUTOCAD,ORCAD,P-CAD,CAM-350,CAM2000 etc.
Quality Standards	IPC-A-600F and MIL-STD-105D CHINA GB<4588>
