Product Specifications
| Prod Model: |
customized size |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Function: |
Identification, Payment, Encrypt/Decrypt, Information |
| Material: |
PVC |
| Frequency: |
Low Frequency |
| Mini Size: |
Customized Size |
| Lf/Hf/UHF: |
125kHz/13.56MHz/860-960MHz |
Product Description
Material: ABS/PVC/PET, epoxy
Size/shape: Customized size, square/round shape, clamshell shape, or other shape on demand
125KHz LF contactless IC chip, support standard: ISO14443A
TK4100, EM4100/EM4102/EM4200
Mango TK4100
Atmel T5557/T5567
NXP Hitag1/Hitag2
Reading dustance: 1-8cm
13.56MHz HF contactless IC chip, support standard ISO14443A
NXP Mf1 Std 1k
NXP Mf1 Std 4k
NXP ultralight
FM FM11RF08
NXP ICODE SLI
NXP plus S2k/4k
NXP DESFire D21/D41/D81
R/W range: 1-8cm
860-960 MHz contactless chip
U-Code G2XL, U-Code G2XM
Alien H3, Higgs-2,
Higgs-3; Impinj Moza3, Impinj Moza2
Supported Standard: ISO18000-6C\EPC Class1 Gen2
R/W Distance: 2-10m, Distance from the tag and reader antenna size of the decision.
Other crafts: With color/logo printing, laser engraved UID code, Printed serial No.
Applications: Key to community/building, hotel room, emplyee ID, student ID, pet/animal tracking and etc
|
Contactless Smart Card/RFID |
Low Frequency |
Memory |
ISO Standard |
|
TK4100/EM4100/EM4102/EM4200 |
125KHz |
8 byte (read only) |
/ |
|
EM4305 |
125KHz/134.2KHz |
64 byte |
11784/85 |
|
EM4450 |
125KHz |
128 byte |
/ |
|
T5577 |
125KHz |
28 byte |
/ |
|
Hitag 1 |
125KHZ |
256 byte |
/ |
|
Hitag 2 |
125KHz/134.2KHZ |
32 byte |
/ |
|
Hitag S256 |
125KHz/134.2KHZ |
32 byte |
/ |
|
Hitag S2048 |
125KHZ/134.2KHz |
256 byte |
11784/85 |
|
RFID Smart Card |
HF/UHF |
Memory |
ISO standard |
|
Mifare Desfire EV1 2k, CPU |
13.56MHZ |
2k byte |
14443A |
|
Mifare Desfire EV1 4k, CPU |
13.56MHZ |
4k byte |
14443A |
|
Mifare Desfire EV1 8k, CPU |
13.56MHZ |
8k byte |
14443A |
|
I-Code SLI |
13.56MHz |
128 byte |
15693 |
|
Mifare Ultralight |
13.56MHz |
64 byte |
14443A |
|
Mifare Ultralight C |
13.56MHz |
192 byte |
14443A |
|
NXP Mifare 1k, Fudan F08 |
13.56MHz |
1K byte |
14443A |
|
NXP Mifare 4k, Fudan F32 |
13.56MHz |
4K byte |
14443A |
|
Alien H3 |
860-960 MHZ |
512 bits |
ISO18000-6C/EPC C1 |
|
Impinj M4 |
860-960 MHZ |
512 bits |
ISO18000-6C/EPC C1 |
|
ISSI 2k |
860-960 MHZ |
2K byte |
ISO18000 |
|
Contact IC Card |
Type |
Memory |
ISO Standard |
|
SLE5542/5528, FM4442/4428 |
Encryption IC |
256 byte/1k byte |
ISO7816 |
|
AT24C02/04/08/16/64 |
Storage IC |
2k/4k/8k/16k/64k byte |
ISO7816 |
|
CPU IC 4k/16k/32k/64k |
CPU |
4k/16k/32k/64k |
ISO7816 |
|
Product Name |
Plastic Card without IC Chip |
|
Material |
PVC / ABS / PP / PETG / Clear PVC/PLA |
|
Size |
ISO 7810 Credit card size(3.375" * 2.125" ) or Customized size/shape |
|
Thickness |
0.76mm(30mil) / 0.5mm(20mil) / 0.25mm (10mil) or on demand |
|
Printing |
CMYL/Pantone color offset printing / silk printing / digital printing |
|
Surface Lamination |
Over laminated into glossy, matt or frosted |
|
Magnetic stripe Card |
300 OE lo-co, 2750/3000 OE hi-co magnetic stripe |
|
Design format |
AI/ CDR/ PSD/ PDF/EPS |
|
Other Card Crafts |
Barcode/QR code/embossing/hot foil/hologram stamping/signature panel/varnish oil finish/laser engraving/anti-fake printing/dand with photo/spot UV printing/hidden UV printing, etc |
|
Applications |
Gift card, membership/VIP card, ID card, warranty card, scratch card, lottery card
Irregular card, bank card, discounting promotion card, shopping card, etc |
|
Our advantage |
1) We have separate factory which reaches Visa/Master card standard
2) We have very large capacity in smart card & plastic manufacture, which can make sure fast delivery
3) Very competitive price
4) Good service after sale
5) OEM/ODM is welcome |
ZDCARD Group is based on Shenzhen Zhengdong Industrial Co., Ltd. After more than 10 year high speed development, we integrate R&D and production of smart cards, chips, and RFID. We supply system solution for R&D, application and project implementation. We also produce all sorts of transparent pre-printed package and large size plastic specialty printing. We are a national hi-tech multinational enterprise with annual sales volume over 200 million RMB.
We invested 300 million RMB on our own industrial zone covering 30, 000 square meters in Longgang District. The zone includes production and R&D of smart cards, RFID and PVC package, which is the biggest and strongest in the world. We are the production and research center of Sun Yat-sen University and we established Guangdong Zhengdong Chengxin Smart Technology Co., Ltd with Micro-Electronics Research Center of Sun Yat-sen University. There are 50 doctors, post-doctorals and professors working for us. Our national lab is an important R&D base of chip, COS, Smart City and logistic solution. Nowadays, our group is working with government to build up a Chinese Chip, Chinese Brain business strategy.
The production management is strictly in compliance with the ISO9001 quality management system and ISO14000 environmental management system and based on the specific features of the products, forming ZDCARD's own management model. ZDCARD is also characterized itself by its reasonable talents pool, integration of both the Chinese and western culture and confluence of wisdoms.
The super-scale production, flexible quality services and added value to our clients are our core
Business philosophy.
Cards Type and application: All kinds of ISO7801-compliant PVC cards such as pre-paid cards
Inquiry cards, bank cards and other magnetic stripe cards; Score cards, membership cards, gift cards and other bar code cards; Scratch cards; Smart cards such as healthcare, social security, public transportation and campus cards.
Equipment: 2 world's state-of-the-art Heidelberg4-olor offset printing presses, 2 automatic cutting
And laminating machines, 5 automatic scratch card stamping and packaging equipment, 2 magnetic mounting and writing devices, 5 convex code printers, multiple DOD and laser coding printers.
Main Customers: Wall-Mart, Carrefour, BESTBUY, McDonald and GOME in the retail/F&B sectors,
Holiday inn hotel, Vienna hotel, Sands rewards club; Beijing Tongren Hospital, Southern Air Force
General Hospital; Nigeria voter's card, Moscow subway cards, Iran subway tickets; Asia cell, Yemen
Mobile, China Mobile; Indonesia ID cards; South Africa Insurance cards.
