Product Specifications
| Prod Model: |
XKJ-400, XKJ-450, XKJ-480 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Sales Market: |
20 More Than Countries |
| Warranty: |
1 Year |
| Flooring Area: |
500 Sq.M |
| Control Way: |
Automatic PLC System |
| Capacity: |
500-1500kg/H |
| Devulcanizer Heating Mode: |
Electrical or Oil |
| Type: |
General Rubber Machinery |
| Type Of General Rubber Machinery: |
Material Processing Machine |
| Type Of Tire Machinery: |
Rubber Regeneration Machinery |
| Certification: |
CE, ISO |
Product Description
Characteristic
1. Environmental protection and energy saving: No waste water, waste gas, using circulating water cooling. Plasticizing powder
Consumption per ton of 100-170KW;
2. Safety: Atmospheric pressure conditions of production, the operator feeding on the ground;
3. Easy operation: PLC control, man-machine interface operation;
4. Each module has a real-time measurement value of feeding, discharging, water temperature into the PLC control system;
5. Each module individually sets temperature, temperature error within ± 1 ° C;
6. Using electromagnetic heating;
7. Products do not stick on conveyer, no need to clean up, with production while cleaning function;
8. Process parameters of memory function, memory function formula, etc;
9. Easy installation and maintenance, safe and reliable and remote maintenance.
|
Version & Parameters |
XKN-4 8 0/ 612 ZG-B |
XKN-450/510ZG-B |
|
Front Roll diameter*Roll length (mm) |
φ4 8 0×100 0 |
φ450×1 000
|
|
Back roll diameter*Roll length (mm) |
Φ 612 ×100 0 |
φ510×1 000 |
|
R oller working surface (mm) |
1000 |
1000 |
|
Front roll surface speed(m/min) |
32 |
28.63 m/min |
|
Back roll surface speed(m/min) |
5 9 |
56 |
|
Front and back roll of Friction ratio |
1:1. 84 |
1:1.957 |
|
Max nip(min) |
10 |
10 |
|
Feeding capacity per hour (kg) |
30-50 |
18-35 |
|
The main motor model and Power (kw) |
Model: Y280-6 Power:55 |
Y280-6-55KW |
|
Reducer model/ratio |
ZSYF355- 31.5 |
ZSYF355-28 |
|
Bearing |
23052CK/3WW |
23052CA/W33 |
|
Lubricating mode |
Thin oil lubricatio n |
Thin oil lubricatio n |
|
Rotate mode |
Moto r / reducer direct-coupled |
Moto r / reducer direct-coupled |
|
Size(l/w/h) |
5200×1970×1860 |
4 2 50×1850×1 870 |
|
Weight(kg) |
1 8 000 |
7600kg |
Qingdao Eenor SCIENCE&TECHNOLOGY Co., Ltd is a professional production of rubber machinery company, has the independent production companies and import and export corporation. The company has the abundant technical force and rich production experience. Our main products: Plate vulcanizer, open mixing mill, mixer, tire vulcanizing machine, rubber cutting machine, rubber extrusion machine, rubber tile vulcanizing press, tyre crusher etc. Complete sets of equipment are: Ordinary conveyor belt production line, waste tyre reclaimed rubber powder production line. We can also according to the customers request; Design and manufacture all kinds of standard rubber machinery and equipment.
My company's products have passed the certification of the various, such as: Plate vulcanizing machine has passed the SGS certification, scrap tire rubber powder production equipment certified by BV certification (France). Product best-selling more than 30 provinces and regions, and exported to southeast Asia, the Middle East, Africa, Europe and the America and other 20 shelves and regions.
