Rectangular Aluminum Foil Container Machinery

Name: Rectangular Aluminum Foil Container Machinery
Brand: China-Manufacturer-Directory.com
SKU: 740249775
Availability: InStock
Rating: 4.6 (114 reviews)

Supplier:	Zhangjiagang Auto-Well Automation Equipment Co., Ltd.
Price:	US $ 30000-40000/Piece
Min Order:	1/Set
Quantity::
Trade Terms:	FOB

Product Specifications

Prod Model:	ATW-45T
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Model No:	Atw-45t, Atw-63t, Atw-80t
Max. Material Roll Diameter:	650mm
Max. Material Roll Width:	750mm
Feeding Tolerance:	+/-0.3mm
Feeding Speed:	0-35m/Min
Dimension(LWH):	20001450900mm
Working Voltage:	380V/50Hz
Certification:	ISO9001:200, ISO 9001:2008, CE Certificate
After-Sales Service Provided:	Engineers Available to Service Machinery Overseas
Mould Material:	Imported From Japan and Europe

Product Description

Aluminium Foil Container Making Machine

Components of Aluminum Foil Container Machine

ATW ALUMINUM FOIL CONTAINER MACHINE is widely used for manufacturing aluminum foil food container.

- Speed Can Be Adjusted.
- Complete with PLC Control Panel Board
- Aluminum Foil Container Machine is Composed of:

1. Auto-Lubricated Feeder
2. Yangli Brand Pneumatic Press
3. Siemens Electrical Control Panel
4. A Collection Desk
5. Aluminum Foil Container Mould
6. Auto Conveyor (optional)
7. Auto Aluminum Foil Container Counter & Stacker (optional)
8. Auto Aluminum Foil Scrap Collector (optional)
9. Scrap Collector (optional)
10. Air Compressor (optional)
11. Hand Support Forklift (optional)

AUTO-WELL:
1) Our own factory manufactures the aluminum foil related machine and provides the overall service
2) We concentrate on aluminum foil field several years. We have a body of engineers who have years of experience.
3) Warranty is 1 year since the machine is arrived in buyer's place.
4) During the warranty time, if the wearing parts have been damaged by non-person or cannot use, seller will send the spare parts to buyer for free. But buyer has to bear the transportation charge.
5) Technical support supplied by seller forever.

How Many Types for Our Aluminum Foil Container Machine?
We have three types: ATW-45T, ATW-63T, ATW-80T.
Please tell us the sizes of containers you want to make, like length*width*height, then we will let you know you should take 45T or 63T or 80T press, and we will quote to you mould price accordingly.
Any more questions, please feel free to contact with Minnie Chen by Email
Mobile Phone: +86 13301568836
Many thanks for your kind attention! ! !

Model	ATW-45T	ATW-63T	ATW-80T
Nominal PRESSURE(KN	400	630	800
Slide Block Stroke(mm)	100-260mm(3.94" -10.24" )	120-260mm(4.72" -10.24" )	140-260mm(5.5" -10.24" )
Slide Stroke Per Minutes	70-50	70-50	60-45
Maximum Die Set Height(mm)	270-400(10.63" -15.74" )	310-450(12.2" -17.71" )	325-450(12.7" -17.74" )
Die Set Height Adjustment(mm)	60mm(2.36" )	70mm(2.76" )	80mm(3.14" )
Slide Bottom Size(mm)	410340mm(16.14"13.39" )	480400mm(18.9"15.75" )	560460mm(22"18.1")
Stem hole Size(mm)	φ6060mm(2.36" 2.36" )	φ6065mm(2.36" 2.56" )	φ6075mm(2.36" 2.36" )
Bolster Surface Size(mm)	810440/990750mm(31.89"17.32"/38.98" 29.53" )	870520/1000800mm(34.25"20.47"/39.37" 31.5" )	1000600/1200800mm(39.3"23.6"/47.2" 31.4" )
Total Power(KW)	5.5	5.5-7.5	7.5
Weight(Kg)	3800-4500	5500-6300	8000-9000
Overall Dimension Before Changed(mm)	144010802300mm(56.69"42.52" 90.55" )	161012002500mm(63.39"47.24" 98.43" )	200013002900mm(78.7" 51.1" 114" )
Overall Dimension After Changed(mm)	155011502500mm(61.02"45.28"98.43")	180013002700mm(70.87"51.18"106.3")	220014503100mm(86.6"57"122" )

Zhangjiagang Auto-well Automation Equipment Co., Ltd. Ismanufactuer, located in ZHANGJIAGANG city, jiangsu province, we are professional in designing and making the, Alu foil container machine, Mould, and Alu foil rewinder.

Our products have been exported to Italy, Saudi Arabia, Bahrain, South Africa, Australia, Iran, Czech Republic, Syria, Dubai and so on more than 30 countries.

We are manufacturer, and we will provide you good after-service.

We will be your good consultant on the whole project, such as we will provide you details on the material, lubricating oil, mould etc.
