Red Glass Filters for Optical Instrument

Name: Red Glass Filters for Optical Instrument
Brand: china-manufacturer-directory.com
SKU: 705730672
Availability: InStock
Rating: 4.7 (41 reviews)

Price:	US $ 0.5-50piece
Trade Terms:	FOB,CFR,CIF
Min Order:	10piece
Pay Type:	L/C,T/T,Paypal,Western Union

Contact Supplier

Showroom Product Company Profile

details

Red Glass Characteristic

Type	Thickness(mm)	A[2856K]			D65			Chemical Stability		ND	α×10-7 (/ºC)	Tg (ºC)	Ts (ºC)	S
Type	Thickness(mm)	x	y	Y	x	y	Y	DA	DW	ND	α×10-7 (/ºC)	Tg (ºC)	Ts (ºC)	S
HB600	2	0.680	0.319	27.0	0.675	0.325	16.5	1	2	1.523	103	527	605	2.64
HB610	2	0.695	0.305	18.4	0.690	0.310	10.7	1	2	1.523	103	527	605	2.64
HB630	2	0.713	0.287	10.4	0.711	0.289	5.5	1	2	1.523	103	527	605	2.64
HB640	2	0.724	0.276	5.0	0.723	0.277	2.4	1	2	1.523	103	527	605	2.64
HB650	2	0.728	0.272	3.2	0.728	0.272	1.5	1	2	1.523	103	527	605	2.64
HB670	2	0.731	0.269	1.1	0.730	0.270	0.5	1	2	1.523	103	527	605	2.64
HB680	2	0.734	0.266	0.3	0.734	0.266	0.1	1	2	1.523	103	527	605	2.64
HB700	2	0.735	0.265	0.0	0.735	0.265	0.0	1	2	1.523	111	534	592	2.64
HB715	3							5	4	1.523	111	534	592	2.77

Technical Request

Type	Thickness(mm)	λtj(nm)	λ0(nm)	Tλ0(%)	K
HB600	2	600±10	680	≥88.7	≥1.2
HB610	2	610±10	680	≥88.7	≥1.2
HB630	2	630±10	700	≥88.7	≥1.2
HB640	2	640±10	720	≥88.7	≥1.2
HB650	2	650±10	720	≥87.5	≥1.0
HB670	2	670±10	750	≥87.5	≥1.0
HB680	2	685±10	800	≥83.6	≥0.8
HB700	2	700±10	800	≥79.8	≥0.8
HB715	3	720±10	800	≥80.0	≥0.8

Class Of Bubble, Stripe, Stress

Type	Bubble	Stripe	Stress
HB600	C-B	3C	3
HB610	C-B	3C	3
HB630	C-B	3C	3
HB640	C-B	3C	3
HB650	C-B	3C	3
HB670	C-B	3C	3
HB680	C-B	3C	3
HB700	C-B	3C	3
HB715	C-B	4	3

Prod Model:	HB600-HB715
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Size:	6mm-200mm
Type:	Color Filter
Principle:	Cut-off Filter
Material:	Glass
Shape:	Round
Certification:	SGS

Our company supplies different kinds of products. High quality and favorable price. We're pleased to get your Inquiry and we will come back to as soon as possible. We stick to the principle of "quality first, service first, continuous improvement and innovation to meet the customers" for the management and "zero defect, zero complaints" as the quality objective. To perfect our service, we provide the products with good quality at the reasonable price.
