Product Specifications
| Prod Model: |
1'' 1/2'' 3/4'' |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| We Can Offer Certification: |
CE, SGS,ISO9001,RoHS |
| Material: |
Galvanized Iron Wire |
| Hole Shape: |
Square |
| Mesh Size: |
1/4 Inch |
| Surface Treatment: |
Galvanized |
| Weave Technique: |
Plain Weave |
| Application: |
Sieving Mesh |
| Color: |
Green |
| Type: |
Welded Mesh |
| Certification: |
BV |
| Condition: |
Used |
Product Description
Galvanized Welded Wire Mesh, Stainless Steel Welded Wire Mesh and PVC Welded Wire Mesh with high quanlity,favorable price and excellent service.
Opening: 1/4"x1/4" to 6"x6"
Wire diameter: 0.45mm-4.5mm
Width: 1m,1.22m,1.524m,1.82m,2.0m etc., custom require available at request.
Roll length: 15m,30m,50m etc,. custom require available at request.
Material:
Electro galvanized wire, hot-dipped galvanized.
We choose the best low carbon wire or stainless steel wire material available in China.
The high quality & reasonable price product is from the right material.
Welding type:
Electro galvanized before welding wire mesh
Electro galvanized before welding wire mesh
Hot-dipped galvanized before welding wire mesh
Hot-dipped galvanized before welding wire mes
Iron/galvanized wire+pvc coated
Stainless steel 304,316 wire
We choose the best low carbon wire or stainless steel wire material available in China.
The high quality & reasonable price product is from the right material.
Specification
| Specification List of Welded Wire Mesh |
| Opening | Wire Diameter |
| In inch | In metric unit (mm) |
| 1/4" x 1/4" | 6.4mm x 6.4mm | 22,23,24 |
| 3/8" x 3/8" | 10.6mm x 10.6mm | 19,20,21,22 |
| 1/2" x 1/2" | 12.7mm x 12.7mm | 16,17,18,19,20,21,22,23 |
| 5/8" x 5/8" | 16mm x 16mm | 18,19,20,21, |
| 3/4" x 3/4" | 19.1mm x 19.1mm | 16,17,18,19,20,21 |
| 1" x 1/2" | 25.4mm x 12.7mm | 16,17,18,19,20,21 |
| 1-1/2" x 1-1/2" | 38mm x 38mm | 14,15,16,17,18,19 |
| 1" x 2" | 25.4mm x 50.8mm | 14,15,16, |
| 2" x 2" | 50.8mm x 50.8mm | 12,13,14,15,16 |
Technical Note:
1,Standard roll length: 30m;width: 0.5m to 1.8m
2,Special sizes available at request
3,Packing: in waterproof paper in rolls. Custom packing available at request. |
| Galvanized Fencing Mesh |
| Opening | Wire Diameter |
| In inch | In metric unit (mm) |
| 2" x 3" | 50mm x 75mm | 2.0mm,2.5mm,1.65mm |
| 3" x 3" | 75mm x 756mm | 2.67mm,2.41mm,2.11mm,1.83mm,1.65mm |
| 2" x 4" | 50mm x 100mm | 2.11mm,2.5mm |
| 4" x 4" | 100mm x 100mm | 2.0mm,2.5mm |
Technical Note:
1,Standard roll length: 30m;width: 0.5m to 1.8m
2,Special sizes available at request
3,Packing: in waterproof paper in rolls. Custom packing available at request |
| PVC Coated Welded Mesh |
| Opening | Wire Diameter |
| In inch | In metric unit (mm) |
| 1/2" x 1/2" | 12.7mm x 12.7mm | 16,17,18,19,20,21 |
| 3/4" x 3/4" | 19mm x 19mm | 16,17,18,19,20,21 |
| 1" x 1" | 25.4mm x 25.4mm | 15,16,17,18,19,20 |
Produce:
Our automatic welding machines can set up any mesh sizes in the market, no matter it's standard type or special requirement;
The fully digital controlled techniques and well-trained staff can ensure the even mesh size and the accurate dimensions of panels.
Package: in waterproof paper in rolls,custom packing available at request.
Payment term:
T/T(30%T/T paid in advance and 70% paid against of BL copy), irrevocable L/C at sight, can be negotiable . .
Sample:free sample sent on request.
Guarantee:
1.shortest delivery time as we have 200-500rolls for stocks(normal size).
2.We guarantee our customers will get right material and sizes,enough weight,on time delivery at our best service and price
3.The goods can be returned or compensated if the quality is not ok
4.There is no "cheat" and "misunderstanding" in ADS
