Reverse Osmosis Water Processing System/Equipment

Product Specifications

Prod Model:	RO-10T
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Shipment Terms:	by Sea
Delivery:	30days After Receive Deposite
Package:	Wooden Case
Warranty:	1year
Certificate:	CE, ISO, SGS

Product Description

reverse osmosis water processing system/equipment

The water treatment consists of booster pump, pretreatment units (including quartz sand filter, active carbon filter and micropore-filter), high pressure pump, reverse osmosis (RO) membrane, conductivity meter, UV sterilizer and controls. The system is used to remove residual suspended solids and organic matter from water and kill bacteria and virus. The portable water is filtered and perfected in this way. The system is unattended and controlled by PLC. It automatically monitors high volume water filtration and long service life.
Standard Features:
1. Fiber Glass RO Membrane Housings
2. Famous SPECK Brand Direct Drive high pressure Pump
3. Brine and Product Flow meters
4. High and Low Pressure Safety Shutdown
5. Multi-medium Pre-filter (Fiber Glass tank or 316SS Tank)
6. 316L SS or PP Pre-filter Cartridges
7. Stainless High and Low Pressure Gauges
8. Stainless High Pressure Valve
9. Automatic Fresh Water Diversion
10. Heavy Duty Motor
11. Long-life 304SS Compact Frame
12. Pressure Vessels with Stress Reduction
13. Stainless fitted pressure pump
14. Rejection 99.5%, more than 20% Recovery. Permeate TDS <450 PPM



Why Choose Us
1. Each water filling machine element tha contacts with the liquid is made of high quality Stainless steel 304, if needed, SS 316 is also available.
2. The water filling machine adopts bottle neck holding transmission technology to realize fully automatic rinsing, filling and capping.
3. Most elements of the electrical system use famous international brand, such as Mitsubish, Omron brand.
4. The water filling machine obtain the advantages of good abrasive resistance,high stability,low failure rate, etc. The
quality of the equipments reaches the international advanced level.
5. Advanced technologies, human-machine interface touch screen and PLC program control are adopted in this machine.
6. Nozzles in the grab can guarantee the complete wash of the interior of the bottle.
7. Easy to operate, save the cost of workers.

Our Services
1 year quality warranty and supply spare parts at low cost for life span after sale. We keep the original
drawings of spare parts, so it can match with the rest part of machine.
2. 24 hours/365 days online technical service.
3. Training offered


Model	Outcome capacity (Ton/h )	Motor power (kw)	Membrane	Entrance Diameter (mm)	Size(L*W*H) ( mm)	Weight (Kg)
T-1	1	1.5	4040	32	1300*600*1400	100
T-2	2	3	4040	38	1400*600*1400	200
T-3	3	4	8040	48	1600*750*1750	200
T-4	4	5	8040	48	2550*750*1750	250
T-5	5	7	8040	60	2550*750*1750	300
T-10	10	11	8040	60	3000*800*2000	600
T-15	15	16	8040	72	3000*1250*2000	840
T-20	20	30	8040	60	3000*1800*2000	1250
