PP woven bag machinery
1. PP Woven Bag Making Machine is specially designed for PP and HDPE with high quality and excellent performance.
2. Perfect tape quality, Lowest consumption, Best economic benefit.
3. Plastic woven sack, Chemical bag, Foods bag, Rice bag, Sugar Bags, Leno bag, Jumbo bag, FIBC bag, Contain bag, Geo textile, Tarpaulin, Carpet backing tape, Artificial grass tape, etc.
Manager:Eric
Mobile？phone:+8613676510195
|
Model |
SJPL65/30-700/112 |
SJPL 90/33-1000/160 |
SJPL /30-1200/192 |
SJPL 120/30-1500/256 |
|
Max. extrusion capacity |
180kg/h |
280kg/h |
350kg/h |
490kg/h |
|
Motor of extruder |
60kw |
90kw |
120kw |
160kw |
|
Dia. of screw |
65mm |
90mm |
100mm |
120mm |
|
Ratio of screw L/D |
30: 1 |
33: 1 |
30: 1 |
30: 1 |
|
Revolution of screw |
20-160r/min |
20-120r/min |
30-120r/min |
30-120r/min |
|
Width of die |
700mm |
1000mm |
1200mm |
1500mm |
|
Max. winding speed |
280m/min |
280m/min |
280m/min |
280m/min |
|
Range of flat yarn fibre |
60-200tex |
60-200tex |
60-200tex |
60-200tex |
|
Stretching ratio |
4-10 |
4-10 |
4-10 |
4-10 |
|
Number of winder |
112spindles |
160spindles |
192spindles |
256spindles |
|
System installed capacity |
237kw |
300kw |
320kw |
400kw |
|
Normal operational capacity |
160kw |
180kw |
190kw |
230kw |
|
Weight (About) |
20000kg |
27000kg |
30000kg |
32000kg |
|
Overall dimension (L× W× H) |
26500× 3200× 2600 |
32000× 3200× 2600 |
35000× 3200× 2600 |
39000× 3200× 2600 |
