Product Specifications
| Prod Model: |
TTCE-K720 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Work Power: |
24VDC (Max. Current 2A, Static Current 0.1A ) |
| Interface: |
RS232 Optional |
| Card Stay Position: |
Multiple Card Stay Position |
| Available Card: |
Width54 ± 0.5 Mm Length 85 ± 0.5 Mm |
| Stacker Capacity: |
150PCS Standard Cards Based on The Thickness of 0. |
| Few Card Alert: |
7~50 PCS(Preset 15PCS of 0.76mm Thick Cards) |
| Install Dimension: |
Follow Our Instruction |
| Weight: |
2.5kg |
| Certification: |
RoHS |
| Type: |
Barcode Card Dispenser |
Product Description
Application
. Parking lot management system
. Automatic vending system
. Subway or public transportation card issue
. Park ticket vending system
. Card initialization issue
Character
1. Barcode reading equipment is installed on dispensing chancel, can read barcode on the card directly.
2. Extended card stacker, standard stacker can load 150PCS card, through extended stacker can load 300PCS.
. Adjustment button
Can adjusting card space to support card thickness between 0.2 to 2.0mm.
3. Smart alert function
When card pre-empty/empty, and have a trouble in dispensing, will be alerted by machine.
4. Super card dispensing ability
5. Error card box can hold 25PCS card
