Roofing PE Foam Thermal Insulation High Reflective Aluminum Foil XPE Foam

Product Specifications

Prod Model:	XPE FOAM
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Density:	25-330kg/M3
Thickness:	0.5-100mm
Max Width:	2.5m
Features:	Heat Insulation, High Reflective
Color:	White
Refractoriness:	-70-80
Material:	PE
Apparent Density:	25-330kg/M3

Product Description

Roofing PE Foam Thermal Insulation High Reflective Foil  polyethylene Foam

Features & Applications:
1. Light weight & intensity and good flexibility, cushioning
2. Invariable if it is attacked repeatedly;
3. Low thermal conductivity and superior heat insulation.
4. Outstanding safety and enviromentally friendly;
5. Easy to install, high efficiency.
6. Cost effective and versatile.
7. Maintenance free.

Good ability
CYG foam insulating products with good flexibility make them suitable for bent and irregular pipes in construction, saving both labor force and cost
Vibration Resistance
CYG foam heat-proof and heat-preservation plastic-rubber with high elasticity, can reduce the vibration and resonance of the hot /cold water pipes utmost
Good fire-blocking
This product has fire-blocking and smoke-reducing property, when burned, its density is very low and doesn't melt, without any small fire ball left and with the merit of self-extinguishing.
According to the standard of GB/T 8624 Method for grading flammability of construction material, this is the flame resistant product of grade B1 enabling to secure the satiety
Low conductivity factor
Conductivity of this material is 0.034W/mk at an average° C. As this product has high heat-releasing ratio, it can get the same heat-preservation effect at less half thickness of other insulating product under the same condition, saving not only space but also cost.

Application of XPE Insulation Material:
1) Roof, wall, floor, Attic for heat insulation and thermal insulation;
2)Shells of air conditioner and water heater;
3)Protective coatings of water pipe and ventilating pipe;
4)Machinary packing;
5)Making ice package

Emittance	0.03
Reflectivity	97%
R-Value	Up to R-11
Flame Spread	25
Water Vapour Transmission	0.012 g/m2 KPA
Fungi Growth	No Fungi
Corrosion	Doesn't generate



thermal conductivity	<0.040W/m@k
apparent density	≤28±2kg/m³
compressive strength	≥0.185
combustion level	B2
water absorption	≤0.05g/cm2
Length	≤300M
width	≤2.5M

Payment terms:T/T
MOQ:1) 3mm-4mm thickness,MOQ3000sqm
     2)5mm-7mm thickness,MOQ2000 sqm
     3)thickness more than 8mm,MOQ 1000 sqm
Delivery date from the Date of Order:15working days


Company info

CYG TEFA Co.,Ltd has 13 years of production experience.We're the biggest and the most professional irradiation crosslinked polyethylene conductive foam manufacturer in China and has the most complete crosslinked polyethylene foam products. Our main products are Crosslinked PE foam material, IXPE foam, XPE foam, Conductive IXPE foam; ESD foam tray, ESD packing material; Beach mat,camping mat,sleeping mat, yoga mat;etc  Now, we have 2 factories and 8production lines. .

Our certificates
ISO9001,ROHS, SGS, UL ,REACH, EN, etc.
