Product Specifications
| Prod Model: |
HCC2200 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Magnetic Stripe: |
Min 500, 000 Swipes |
| Sam Card: |
Min 5, 000 Times |
| Power Supply: |
DC 5V10% 300mA Maximum |
| Working Conditions: |
0-40 10%-90% Rh Non-Condensing |
| 0-40 10%-90% Rh Non-Condensing: |
450mmx210mmx60mm |
| Dimensions: |
450mm´210mm´60mm |
| Weight: |
Approx. 1.6kg |
| Housing: |
Plastic PC, Ivory Color |
| Interface: |
RS232, PS/2 CT, 9600/4800/2400/1200 BPS at Option |
| Operation Indication: |
LED, Beeper |
| Certification: |
ISO |
| Type: |
Data Collector |
| Data Collector Operating System: |
Win CE |
| Data Collector Signal Transmission: |
Wired |
Product Description
General
HCC2200 multifunctional keyboard is an all-in-one terminal keyboard which integrates magnetic stripe/ &smart card technology, ideal for highly secure electronic debit transaction, user identification or password memory in banks, securities and POS system.
Features:
All-in-one smart keyboard largely save counter space
Magnetic stripe and smart card readers are designed in modules and can be inserted or replaced flexibly
Using Cherry MX keys based on gold cross-point technology, with good tactility
Two different key actions (key click/soft contact) available
Laser-engraved keycap symbols are wear-resistant and easy to clean
Manual swiping/landing contact for reading/writing
Automatic recognize ISO/IBM format, writing format set through command
Data be written in track 2 with 210BPI or 75BPI
Can be customized to read non-standard magnetic stripe data
Can read/write card made of any medium, including transparent magnetic card
Different international keyboard layout available, such as US/DE/GB/FR etc.
Specifications:
Data Format Standard IBM for passbook, ISO/ANSI for magnetic cards
ISO7816 for CPU card and memory card
Interface RS232, PS/2 CT, 9600/4800/2400/1200 BPS at option
Operation indication LED, beeper
Reliability MTBF > 20000H, MTTR < 30 MIN
Manual feeding speed 20cm/s-120cm/s
Service life Keyboard: Min. 50, 000, 000 cycles for KP
Min. 20, 000, 000 cycles for SP
Magnetic stripe: Min 500, 000 swipes
IC card: Min 500, 000 insertions
SAM card: Min 5, 000 times
Power supply DC 5V10% 300mA maximum
Working conditions 0-40 10%-90% RH non-condensing
Dimensions (LxWxH) 450mmx210mmx60mm
Weight Approx. 1.6Kg
Housing Plastic PC, Ivory color
Model Description
2200X1-X2X3X4
Type X1 Interface X2 Magnetic Tracks X3 IC Card Reader X4 PSAM
2200
Mulitifunctional
Keyboard R RS232 Series port 4 1/2 tracks 0 No 0 NO
5 2/3 tracks 1 1 1 1
6 1/2/3 tracks 2 2 2 2
3 3
For example
HCC2200 R 413-Keyboard, with RS232 series interface, 1/2 magnetic strips reader, 1 smart card reader module, 3 PSAM module.
Data Format Standard |
IBM for passbook, ISO/ANSI for magnetic cards
ISO7816 for CPU card and memory card |
Interface |
RS232, PS/2 CT, 9600/4800/2400/1200 bps at option |
Operation indication | LED, beeper |
Reliability |
MTBF > 20000H, MTTR < 30 MIN |
Manual feeding speed |
20cm/s-120cm/s |
Service life |
Keyboard: min. 50,000,000 cycles for KP
min. 20,000,000 cycles for SP |
Magnetic stripe: min 500,000 swipes |
IC card: min 500,000 insertions |
SAM card : min 5,000 times |
Power supply |
DC 5V10% 300mA maximum |
Working conditions |
0~40 10%~90% RH non-condensing |
Dimensions (L ´W ´H) |
450mm´210mm´60mm |
Weight | Approx. 1.6Kg |
Housing | Plastic PC, Ivory color |
Model Description
2200x1-x2x3x4
| Type | X1 | Interface | X2 | Magnetic Tracks | X3 | IC Card Reader | X4 | PSAM |
2200
Mulitifunctional
Keyboard | R | RS232 Series port | 4 | 1&2 tracks | 0 | No | 0 | NO |
| | | 5 | 2&3 tracks | 1 | 1 | 1 | 1 |
| | | 6 | 1&2&3 tracks | 2 | 2 | 2 | 2 |
| | | | | | | 3 | 3 |
| | | | | | | | |
