Product Specifications
| Prod Model: |
CW-6200AT |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Voltage: |
110V-220V |
| Frequency: |
50/60Hz |
| Refrigerant: |
R-22 / R-410A |
| N.W: |
69kgs |
| G.W: |
79kgs |
| Dimension: |
67 X 47 X 89 Cm |
| Packing Dimension: |
74 X 60 X 109 Cm |
| Type: |
Water-Cooled |
| Certification: |
CE |
| Condition: |
New |
| Selected Voltage: |
110V/220V, 50Hz/60Hz |
| Application Fields: |
Industrial Cooling |
| Application Machine: |
Industrial Cooling |
Product Description
S&A water chiller with dual-circuit refrigeration system
CW-6200AT water chiller with dual-circuit refrigeration system is developed and produced by S&A company, applied to cool 750W-800W water cooled fiber laser machine
CW-6200AT is dual temperature and dual pump chiller of 5100W cooling capacity. It is able to cool the fiber laser and QBH connector at the same time, multiple use for saving cost, space and manual move, quiteconvenient for the user.
Water chiller features:
1. 5100W cooling capacity; optional environmental refrigerant;
2. ±0.5ºC precisely temperature control;
3. The intelligent temperature controller has 2 control modes, applicable to different applied occasions; with various setting and display functions;
4. Dual temperature and dual pump to satisfy different needs of fiber laser device and the lens;
5. With Ion adsorption filtrating and test functions conform to fiber laser device operating requirements;
6. Multiple alarm functions: compressor time-delay protection, compressor overcurrent protection, water flow alarm and over high / low temperature alarm;
7. Multiple power specifications; CE approval; RoHS approval;
