SAE R17 Wire Braid Reinforcement Hydraulic Hose

Name: SAE R17 Wire Braid Reinforcement Hydraulic Hose
Brand: China-Manufacturer-Directory.com
SKU: 745303935
Availability: InStock
Rating: 4.7 (149 reviews)

Supplier:	Hangzhou Haikuo Rubber and Plastic Products Co., Ltd.
Price:	Negotiable/Piece
Min Order:	1000/Meter
Quantity::
Trade Terms:	FOB,CIF

Product Specifications

Prod Model:	SAE R17 Wire Braid Reinforcement Hydraulic Hose
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Product Name:	SAE R17 Wire Braid Reinforcement Hydraulic Hose
Type:	Hydraulic Hose
I.D:	3/16''-2''
W.P:	3000psi / Depend The Size
B.P:	9000psi / Depend The Size
Surface:	Smooth or Cloth
Length:	50/100m
Brand:	Print and Embossed
Color Available:	Black/Blue/Red/Grey/Green
Package:	Roll
Material:	Rubber Blend
Color:	Black/Blue/Red
Capability:	Water/Oil Deliver

Product Description

SAE R17 Wire Braid Reinforcement Hydraulic Hose

Application: High pressure hydraulic applications designed to replace 100R1 where higher pressures and a more flexible hose is required.

Reinforcement: One or two layer steel wire braid

Temperature range: -40° F 212° F; -40° C~121° C

Color available: Black, grey, blue, yellow, red, etc.

Remarks:
1. Sample of Hydraulic Hose is available
2. OEM is welcome
3. Just feel free to contact us if any questions.

Part No.	Hose Size ID		Hose OD		Work Pressure		Bend Radius		Burst Pressure		Weight
Part No.	in	mm	in	mm	psi	mpa	in	mm	psi	mpa	kg/m
HQ-R17-04	1/4	6.4	0.52	13.2	3000	20.7	2	51	12000	82.7	0.17
HQ-R17-05	5/16	7.9	0.58	14.8	3000	20.7	2.16	55	12000	82.7	0.21
HQ-R17-06	3/8	9.5	0.67	17	3000	20.7	2.5	64	12000	82.7	0.25
HQ-R17-08	1/2	12.7	0.83	21.1	3000	20.7	3.5	89	12000	82.7	0.47
HQ-R17-10	5/8	15.9	1.02	25.9	3000	20.7	4	102	12000	82.7	0.59
HQ-R17-12	3/4	19	1.19	30.3	3000	20.7	5	127	12000	82.7	0.75
HQ-R17-16	1	25.4	1.52	38.6	3000	20.7	6	152	12000	82.7	1.46
