Product Specifications
| Prod Model: |
Various |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Application: |
Mining, Construction, Metallurgy |
| Model Number: |
Pf Series |
| Certificate: |
ISO9001-2008 |
| Capacity(Tph): |
20~1100 |
| Power(Kw): |
55~1120 |
| Feeding Size(Mm): |
250~800 |
| Mining Object: |
Metallic and Non-Metallic Ore Excavator |
| Type: |
Crushing Equipment |
Product Description
Sandstone aggregate production line includes vibrating feeder, jaw crusher, impact crusher, vibrating screen, belt conveyor and centrally electric controlling system, etc. The designed capacity is from 50t/h to 1500t/h. To meet customer's specific requirement, we can also add other equipments such as cone crusher, dust catcher on the production line.
Process of sandstone aggregate production line:
Big materials are fed to the jaw crusher evenly and gradually by vibrating feeder through a hopper for primary crushing. After first crush, the material will transferred to impact crusher by belt conveyor for secondary crush; The crushed materials will then transferred to vibrating screen for separating. After separating, the parts that can meet standard will be transferred away as final products, while the other parts will be returned to impact crusher, thus forming a closed circuit. Size of final products can be combined and graded according to customer's specific requirement. We can also equip dust catcher system to protect environment.
|
Model |
Specification
(mm) |
Feeding size(mm) |
Max feed size(mm) |
Capacity
(t/h) |
Motor power(kw) |
Weight(kg) |
|
PF-0607 |
644*740 |
320*770 |
100 |
10-20 |
30 |
10216 |
|
PF-0807 |
850*700 |
400*730 |
300 |
15-30 |
30-45 |
11138 |
|
PF-1008 |
1000*800 |
400*830 |
300 |
30-50 |
37-55 |
12206 |
|
PF-1010 |
1010*1050 |
400*1080 |
350 |
50-80 |
55-75 |
13138 |
|
PF-1210 |
1250*1050 |
400*1080 |
350 |
70-120 |
110-132 |
15200 |
|
PF-1212 |
1250*1250 |
400*1300 |
350 |
100-150 |
132-160 |
17025 |
|
PF-1214 |
1250*1400 |
400*1430 |
400 |
130-180 |
160-200 |
19015 |
|
PF-1315 |
1320*1500 |
860*1520 |
500 |
160-250 |
180-260 |
24600 |
|
PF-1320 |
1320*2000 |
860*2030 |
500 |
300-350 |
300-375 |
29800 |
|
PF-1520 |
1520*2000 |
980*2980 |
700 |
400-500 |
400-480 |
38600 |
|
