Sbm Jigging Machine

Product Specifications

Prod Model:	100*150 Diaphragm Jig
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Other Warranty:	12 Months
Other Color:	Yellow Iron Grey
After Sales Service:	The Whole Time
Spare Parts Supply:	Will Supply Any Time
Other:	Mining,Quarry,Chemical Industry and Construction
The Machines Classification:	Jigging Machine
Other Certification:	CE
Test&Installation:	Professional Engineer Assigned
Voltage:	380V
Weight:	2T
Color:	Grey
Certification:	CE
Customized:	Customized
Warranty:	1 Year
Condition:	New
Type:	Jigging Machine

Product Description

SBM jigging machine:

The twin-
Bucket diaphragm jigging machine has two types of left and right jig surfaces. Our jigging machine is a fixed screen, which is applicable for metallic ores dressing such as placers that contain tungsten or gold, concentrate tin ore, etc...This jig can also be used to select fine particle materials and dress the rough materials, of which the biggest input size is 6-8 mm, but on some particular cases of placer ore dressing, the largest input size can reach 12mm.

The structure of LTS300× 450 twin-
Bucket diaphragm jigging machine are mainly constituted by body, gearing, water segregator, diaphragm, stopcock, etc...The body has one big and one small jig buckets and the diaphragm bucket using the baffle plate without reaching the end to divide them into jigging area and diaphragm area. Jigging process is proceeding through the medium (water) vibration caused by up-down repeated motion of the rubber diaphragm. Motor drives the large leather wheel to rotate through triangle belt and makes the connecting rod of eccentric shaft move up and down so as to drive the up-down movement of the rocker arm connecting to the connecting rod. There are another two connecting rods that connected to the diaphragm, which will make the diaphragm repeat up-down movement to proceed jigging.
According to the ore granularity, we can change the jig frequency of connecting rod and choose different stroke so as to obtain the best jigging effect. The way to change jig frequency is to change belt pulley. There are two jig frequencies: 322 times/ min; 420 times/ min. The way to change different stroke is to loosen the fixed bolts and nuts, pull out the dowel pin and adjust the relative position between eccentric shaft and eccentric adjusting sleeve by rotating it. There are 11 kinds of stroke (0-25.3mm).

SBM jigging machine application range:

It is used for processing minerals like gold, tin, tungsten, titanium, hematite, iron ore, coal and so on. It is especially widely applied in the manganese ore dressing field.

SBM jigging machine precaution:

1. Before startup check and confirm all the bolts of various parts are fixed and no leakage in stopcock and bucket.
2. Please note lubricant grease shall be added regularly on the various pressure oil nozzles.
3. Start loading operating only after the open drive is running normally.
4. No oil spots allowed at the rubber diagram and triangle belt.
