Product Specifications
| Prod Model: |
SC |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| FC Quick Connector: |
Fast Connector for Patch Panels |
| FC/Upc Connector: |
Fast Connector |
| Embedded Connector: |
Fiber Optic Connector |
| Transmission Medium: |
Multimode |
| Structure: |
SC |
| Number Of Cores: |
Single-Core |
| Ferrule Endface: |
PC(',UPC) |
| Light Source TYPE: |
Distribution Frames |
Product Description
Detail:Name: FC Embedded Fast Connector
Ferrule size: 1.25mm
Cable diameter: 0.9mm, 2.0mm, 3.0mm optional
Ferrule end-face: PC
Type: simplex, duplex
Housing color: Blue Beige, Aqua, White, Red, Black, Green
Description:There are many kinds of fiber optic connectors. We supply fiber optic types include: SC, FC, ST, LC, MU fiber optic connector, etc.
Features:FC, SC, LC, MU, ST, MT-RJ, etc connector
Customized specifications welcomed.
Good exchange ability and good durability;
Available in fiber bunch, ribbon fan-out, pigtail available;
Meets ISO9001, ROHS and Bell core GR 326-core standards;
Applications:Telecommunication
Computer networks
CATV networks
Premise installations
Specification:
Insertion loss | SM | ≤0.20 dB |
| MM | ≤0.25dB |
| Return loss | P C | ≥50 dB |
| UPC | ≥55 dB |
| APC | ≥65 dB |
| Durability | <0.20 dB typical change, 1000 mating |
| Ferrule hole sizes | SM: 125.0+1/-0um | concentricity:≤1.0um |
| 125.5+1/-0um | ≤1.0um |
| 126.0+1/-0um | ≤1.0um |
| MM:125 um | concentricity:1≤3 um |
| 127 um | ≤3 um |
| 128 um | ≤3 um |
| Operating temperature | -40~80°C |
Ordering Information:Step 1: Connector Type: FC,SC,LC,ST,MTRJ,MU,MPO,D4,DIN,SMA
Step 2: Connector size: 0.9mm, 2.0mm, 3.0mm
Step 3: Ferrule End-face: PC, UPC, APC
Step 4: Core Type: Single-mode (SM:9/125um), Multimode (MM:50/125um,62.5/125um)
Step 5: Boot color: Black, Blue, White, Red, Yellow, Green, Beige, Aqua
Shipping:Door to Door: by express (such as DHL, UPS, TNT, FedEx etc.)
Airport to Airport: by air
Seaport to Seaport: by sea (our location Shenzhen is a seaport.)
![]()
