Scbh15 Amorphous Alloy Dry-Type Power Transformer

Product Specifications

Product Description

Model

Scbh15 Amorphous Alloy Dry-Type Power Transformer

SH15 energy-saving transformer amorphous alloy: This project had a scientific research on current high loss in the area loss reduction method, put forward the measure for reducing loss of new loss reduction theory and many other measures, and select a pilot area, using different methods to reduce loss. The line loss of the original reduces from 15.3% to 9.3% successfully after reforming. By adopting a number of patented technologies, improve product short-circuit capacity and reduce the operation noise, thereby improving product reliability. The experts from Hunan province electric power company indicate that this technology has reached the leading domestic level; He proposed that it can be widely appreciated over the country, and we can have a further and deeper research on the reason and solution on the loss of network distribution.

30 Years in Electrics Equipment OEM Manufacturing

Standards

GB1094,GB/T6451,GB/T11022,GB7251,GB/T14028,GB/T17467

Working Conditions

Ambient temperature:

Maximum: +40 centigrade degrees

Minimum: -25 centigrade degrees

Maximum average monthly temperature: +30 centigrade degrees

Relatively humidity: at 25 centigrade degrees

Daily average RH: not more than 95%

Monthly average RH: not more than 90%.

Altitude: ≤1000m

Shockproof:

≤3m/s2 horizontally

≤1.5m/s2 vertically

Installation Environment:

No obvious dirtiness, no explosive and corrosive gas or powder. The installation site should have good air ventilation and no furious vibration and shocking forces.

Our Transformer Product Range
S10 S11 S13 oil type transformer:50-31500KVA,6-33KV,50/60HZ,off load tape changer

SZ10 SZ11 oil type transformer:50-31500KVA, 6-33KV,50/60HZ, on load tape changer

SCB9,SCB11 dry type transformer: F grade insulation, 50-3150KVA,6-33KV, 50/60HZ

SCBH15 11KV amorphous alloy dry type transformer:F grade insulation

SGB10 SGB11 11KV dry type transformer:H grade insulation

SBH15 Oil type amorphous alloy transformer 11KV Level

S13-M 1full sealed oil immersed power transformer

Dry type reactor

S(B)H15-16 Amorphous Transformer

BKSC(G)Dry-type shunt reactor

QKSC Dry Startup reactor

Smoothing reactors

KD-LK-type low-pressure filter reactor

Cast resin dry type earthing transformer

Dry type rectifier transformer

Rectifier transformer

Furnace transformer

Note: we can design and manufacture special transformer as customers' requirements.

Ordering Instruction: 1.product model; 2.rated capacity; 3.voltage range; 4.regulation range; 5.frequency; 6.connection symbol; 7. Technical specs for customized transformer.


Workshop
