Product Specifications
| Prod Model: |
SCSI HPCN series 002 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Different Positions Are Available: |
20POS, 26POS, 36POS |
| Application: |
Microwave |
Product Description
Key Specifications/Special Features:
Positions: 20P/26P/36P
Contact current rating: 1.0Amp AC/DC
Voltage rating: 40V AC
Operation temperature: -25 to 85° C
Contact resistance: 35mΩ (maximum)
Insulation resistance: 200mΩ (minimum) at 500V DC
Withstanding voltage: 500V AC for one minute
Insulator material: Glass reinforce polyester (UL94V-0) black
Contact material: Phosphor bronze (C5191-EH) T = 0.3
Contact plating: SN over 50u Ni
Colors: Black
Shroud material: Spec
Solder area: Tin plated (80u-inch lead-free)
Wire accommodation: 24, 26, 28 and 30AWG
