Product Specifications
| Prod Model: |
msp 217 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Delivery Time: |
3 Days |
| Size: |
1/2u Box |
| Application: |
Microphone |
| Type: |
Optical Fiber |
| Certification: |
CE |
| Color: |
Purple |
| Connector: |
DVI |
Product Description
MSP217 SDI to fiber optic, fiber optic to SDI Mini converter SDI Extender
One RGBlink AVMSP converter is internally made up by three parts: Receiver, processor and driver, which connects the output port of the receiver to the input port of the processor, and connects the output port of the processor to input port of the driver. The combinations of the three parts form a series of RGBlink AVMSP converters.
MSP 217-T transmitter is connected with the signal source of camera, the port at rear plate is connected with the input of power supply, RS232 signal. Input of fiber, input of audio, sdi signal input. The switch near sdi interface can be converted into input source of
Input and out resolution and frame
@640X480 @ 70fps
@800X600 @ 70fps
@1024X768 @ 60fps
@1280X1024 @ 30fps
@1600X1200 @ 30fps
@720X480 @ 60fps
@720X576 @ 50fpsv
@1280X720 @ 30fps
@1440x900 @ 30fps
@1400 x1050 @ 30fps
@1680x1050 @ 30fps
@1360x768 @ 30fps
@1920X1080 @ 25fps
@1920X1080 @ 60fps
Environment condition
Working temperature: -25° C~+70° C
Storage temperature: -40° C~+80° C
Relative humidity: 0~95%(non condenses
Fiber Parameter
Fiber option
Meet with the optical connection specification of1000BASE_LX in IEEE802.3z
Fiber cable: One piece of single core and single mode fiber
Input optical center wavelength: 1310nm
Transmitting power: -9.5~-3dBm average optical rate @850nm
Optical receiving sensitivity: -23dBm average optical rate @850nm
Output light modulation amplitude: 180μ W
Input light modulation amplitude: ≤ 15μ W
Relative signal strength: -116 DB/Hz
RL( return loss): ≤ 10 dB
Transmission code rate: 240M Hz~1.65G Hz
Transmission distance: 1~20km single mode fiber
