Product Specifications
| Prod Model: |
HTZH-2H |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Dimension: |
250*150*300mm3 |
| Weight: |
5kg |
Product Description
Products features
1. Fast and save gas: after startup into the measuring state, the measuring time of dew point is about 5min; the measuring time of SF6 purity and SF6 decomposer is about 2min;
2. Self-lock joint: use the self-lock joint imported from German, safe and reliable, without gas leakage.
3. Data storage: high capacity, can store 200 groups test results at the most.
4. Curve function: Large-screen curve display the process of dewpoint measurement
5. Clearly display: the dew point, micro-water (ppm), SF6 purity, SO2, H2S, CO and HF content, and temperature, humidity, time and date, etc, are displayed by LCD.
6. Built-in power supply: built-in 4Ah chargeable lithium battery, filled one time, can work for 10 hours.
Technique parameters
| Purity | Measuring range:0%~100% |
| Accuracy:±0.5% |
| Measuring time:< 2min |
| Dew point | Measuring range:-80ºC~+20ºC |
| Accuracy:±0.5ºC(-80ºC~-60ºC) |
| Response time(+20ºC) | 63% need 5S, 90% need 45S (-60ºC~+20ºC) |
| 63% need 10S,90% need 240S (+20ºC~-60ºC) |
| H2S | Measuring range:0~200ppm |
| The minimum detectable amount:≤0.1ppm |
| Accuracy:±0.5% |
| Stability:0~200ppm |
| Repeatability:≤2% |
| SO2 | Measuring range:0~200ppm |
| The minimum detectable amount:≤0.1ppm |
| Accuracy:±0.5% |
| Stability:0~200ppm |
| Repeatability:≤2% |
| HF(optional) | Measuring range:0~20ppm |
| The minimum detectable amount:≤0.01ppm |
| Accuracy:±0.5% |
| Stability:0~20ppm |
| Repeatability:≤2% |
| CO(optional) | Measuring range:0~1000ppm |
| The minimum detectable amount:≤1ppm |
| Accuracy:±0.5% |
| Stability:0~1000ppm |
| Repeatability:≤2% |
| Temperature | -40ºC~+60ºC |
| Humidity | 0~100%RH |
| Power supply | AC 220V |
| Built-in rechargeable battery |
| Battery performance | Charging time : 20 hours ; can work for 10 hours |
| Weight | 5kg |
| Dimension | 250×150×300mm3 |
| Working temperature | -40ºC~+80ºC |
