Product Specifications
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Color: |
Red |
| Codition: |
New |
| Mining Object: |
Metallic and Non-Metallic Ore Exca |
| Type: |
Crushing Equipment |
| Cafitication: |
ISO900: 2001 |
| Input Size: |
900mm |
| Capacity(T/H): |
10-850t/H |
| Model Number: |
Hammer Crusherpc and Pcz Series |
| Warranty Period: |
12 Month |
| Application: |
Limestone, Coal and So on |
| Tongs' Features: |
Adjustable Tongs |
| Finished Surface: |
Cut Off Tool |
| Cutter Material: |
Hard Alloy |
| Principle: |
Roller Culling |
| Compressive Strength (',For Crushing): |
100-250MPA |
| Crushing Style: |
Impact |
Product Description
Hammer crusher is widely used in mining, cement, coal, metallurgy, construction material
Hammer Crusher is widely used in mining, cement, coal, metallurgy, construction material, and comminution of the medium hard or brittle materials in public roads industry. It crushes materials by the collisions between high-speed hammer and materials. It's features: Simple structure, high reduction ration, high efficiency, etc. The hammer crusher can be used for both dry and wet crushing.
Operating principle of Hammer Crusher:
The motor drives the rotor rotate of the hammer crusher at a high speed through the belt, and on the rotor there are series hammers. When the materials get into the working area of hammers, they are crushed by the rotating hammers of the hammer crusher with high rotation speed, the products which are crushed to meet the required size can be discharged by the outlet and become the final products, the large size products are brought back to the crushed area by the hammers of the hammer crusher for being recrushed until they reached the required size.
|
Type |
RotorD*L (mm) |
Feed size(mm) |
Discharge size(mm) |
Capacity(T/h) |
Power(KW) |
Weight(T) |
|
806 |
800× 600 |
≤ 300-400 |
0-40 |
60 |
55 |
3.8 |
|
808 |
800× 800 |
≤ 400-500 |
0-50 |
80-100 |
75 |
6.5 |
|
1008 |
1000× 800 |
≤ 500-650 |
0-60 |
100-120 |
90 |
8 |
|
1010 |
1000× 1000 |
≤ 600-750 |
0-70 |
120-150 |
132 |
11.5 |
|
1210 |
1200× 1000 |
≤ 650-800 |
0-70 |
150-200 |
185 |
14 |
|
1510 |
1500× 950 |
≤ 800 |
0-80 |
160-250 |
200 |
17.5 |
|
1512 |
1500× 1160 |
≤ 800 |
0-80 |
250-300 |
250 |
19 |
|
1615 |
1650× 1450 |
≤ 900 |
0-80 |
300-380 |
280 |
28 |
|
2015 |
2000× 1500 |
≤ 1200 |
0-80 |
400-500 |
400 |
32 |
