Product Specifications
| Prod Model: |
kbpc3510 |
| Material: |
Element Semiconductor |
Product Description
Style: KBPC3510
Features:
Isolation voltage: 2500V~
Planar passivated chips.
International standard package.
Advanced heat dissipation property.
Low forward voltage drop.
Application:
PWM frequency converter rectifying power, DC Power, Rectifying power, Battery Charging DC power, Inverter welding machine etc.
Specification:
VRRM(Maximum reverse repetitive peak voltage): 1000V
VRMS(Maximum RMS voltage): 700V
VDC(Maximum DC blocking voltage): 1000V
IF(AV)(Maximum average forward rectifying current Tc=55ºC): 35A
IFSM(Peak forward surge current): 400A
VF(Maximum forward voltage, IF=17.5A): 1.1 V
Rth(j-c) (thermal impedance junction to case): 2.0ºC/W
Rth(j-a)(thermal impedance case to air): 10ºC
TJ(Operating temperature): -40~125ºC
Tstg(Storage temperature): -40~150ºC
Hangzhou Tuozhi Electronic Co., Ltd is a specialized manufacturer of electric elements. We have Advanced DC electrical components research and development laboratories and reliability experiment platform.
Hangzhou Tuozhi Electronic Co., Ltd located in Hangzhou, Zhejiang, China, have been specialized in semiconductor area almost 10 years, and we have got ISO9001, ISO14001, RoHS and CE certificate.
The main products include:
Thyristor module
Rectifier module
Thyristor/Diode module
Single-phase rectifier/three-phase rectifier
Bridge Rectifiers
Super Fast Recovery Rectifiers
Quick thyristor
MOS relay
Solid State Relay
Three-phase solid state relay elements
Smart voltage adjustment module
SCR phase-shift voltage regulator
Heatsinks
Instrument and apparatus
Photovoltaic defence-attack diode module
