Single-Phase Energy Meter 32A (YDD32)

Single-Phase Energy Meter 32A (YDD32)
Supplier: Jiaxing Yongxin Electron Co., Ltd.
Price: Negotiable
Min Order: 500/Piece
Quantity::
Trade Terms: By air or sea
contact supplier

Product Specifications

Prod Model: YDD32
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Electric Equipment: Single-phase
Installation: Direct Connected
Power Source: DC Meter
Theory: Induction Meter
Usage: Meter for Industry and Home Use

Product Description

YDD-32 single-phase meter 32A
Static kilowatthour single-phase meter 230vAC, 5(32)A
With SO-interface, for mouting on DIN-rail according to DIN-EN 50 022
Static kilowatthoue single-phase meter 230vAC, 5(32A), 50--60Hz
EN 62053-21(EN61036)
18mm wide(1 module)
Accuracy class1
Power sonsumption(real power)no greater than 0.6W
Starting current no greater than 25mA
Ambient temperature limits:Minus 20 to plus50
Display drum type register with 5 digits for KWH 1 red decimal digit
Pulse interface(SO according to DIN43864)
For datalogger systems
External source min 18v DC to max 27v DC
Max, 27mA, depending on cable length between interface and datallogger
Impulse length greater than 30ms
Impulse constant optical coupler output:2000 Imp/kWh
Jiaxing City Yongxin Electron Co., Ltd. was founded in 1998. It is one of the largest KWH meter counter manufacturers in China, which is professionally engaged in design, production and sale of KWH meter counter, cunrrnet transfoemer, transformer and bobbin etc., it owns a number of patented technologies. Annual output can reach more than 5 million sets of all kinds of specifications counters, 1 million sets of power transformer and 1 million sets of all kinds of 0.1 class current transformer. We own the first class equipment for product development, production and testing of aging to ensure the specification and quality. The company covers an area of more than 14, 000 square meters and its 5, 500 square meters is for standard factory. There are over 80 workers and 15 medium & high garde technicians in our factory. We carry out the ISO9001: 2000 Quality Supervision Guarantee System comprehensively. Our products have exported to Europe, Southeast Asia and Africa etc...

Our company located in Sea Exit of Hangzhou Bay in the Changjiang River Delta with flourishing economy and First-Level Open-Port Jiaxing Harbor Area. Zhapu-Jiaxing-Suzhou Expressway which is in Harbor area connecting with Shanghai-Hangzhou-Ningbo, Shanghai-Nanjing and Shanghai-Beijing Expressway. It also holds straight links with the starting point in the north banks of "Hangzhou Bay Bridge" which has been reputed as the "First Cross-Sea Bridge in the World" under construction. It is nearly 100km away from Shanghai, Hangzhou and Suzhou. It has transport facilities and increasingly important geographical and economical positions.

Our objective is "Technological Innovation, Striving for Remarkable Service, Creating famous 'Quanshang' Brand", sincerely we cooperate with each of our customers. While guaranteeing the present product development, the company is trying to bring favorable conditions and introduce the gifted people in order to develop in the multiple aspects of intellectual electrical, electronic instrument and meter. Welcome vast friends from all quarters come to sincerely cooperation and start business with Yongxin company and jointly create a fine tomorrow. Welcome to visit our website.

Yongxin another new line is senmiconductor mini refrigerator. GRL as the brand and our refrigerator will show the real green life.
