Product Specifications
Prod Model: |
DDS150 |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Voltage: |
220V (Single-Phase) |
Frequency: |
50Hz |
Accuracy: |
Class 1.0 , 2.0 |
Max. Computation Current: |
90A |
Other Service: |
OEM Offered |
Display: |
Digital |
Installation: |
Direct Connected |
Usage: |
Maximum Demand Meter |
Electric Equipment: |
Single-phase |
Theory: |
Electronic Meter |
Power Meter Connection: |
Terminal |
Measured Signal: |
Continuous Wave |
Type: |
Energy Meter |
Product Description
Main Functions
Precise metering of active electric energy
Remote reading of real-time electric quantity through low-voltage line
Remote switching-in and load control, indicating of power-up or power-off
Mutual auto relay
LCD, power failure flashing
Freezing of electric quantity, daily frozen electric quantity kept for 7 days; Daily hour total active power meter code stored for 3 days;
Multi-rate and stepped electric energy supported
Three modes switching supported: Normal, stepped rate, time shared rate
Alarming of loss of phase, current loss, and overloaded power off, overpower load value settable
Event recording, recording of programming, timing, tripping, dumping, and uncapping events
IR communication, RS485 communication, and power carrier communication supported
IR and power line carrier programming available
Features
Low-power consumption, high-performance micro processor used, simply structured, stable performance, ensuring long safe and reliable operation.
Precise metering of active electric energy, no calibration required for long time.
Auto freezing of data such as electric quantity and meter state on the hour or at 0: 00 a. M. Each day, and auto storing of data for reading.
Spread spectrum mode used for power carrier communication, providing reliable and precise data transmission, routing depth up to 7 levels.
After power off, data capable of being stored for 10 years or more
Receiving of auto clock calibration of ranged concentrator or performed in the system
Name | Parameter |
Standards | IEC 62053-21: 2003, DL/T645-1997/2007 |
Voltage | 220V (Single-Phase) |
Current | 1.5(6)A, 5(20)A, 5(30A), 5(40)A, 5(60)A, 10(40)A, 10(60)A, 15(60)A, 20(80)A |
Frequency | 50Hz |
Accuracy Class | 2.0, 1.0, 0.5S; 2.0 (Reactive Power) |
Impulse Constant (imp/kWh) | 6400, 3200, 2400, 1600, 1200, 800, 400, 200 |
Clock Accuracy(optional) | ≤ 0.5s/Day (Refer to temperature of 23 centigrade); |
Data Storage Period | ≥ 10 years, the working time lasts more than 5 years even if power off . |
Power Consumption | ≤ 0.8 W/Phase |
Creeping design | Have the function of intelligent logical anti-creeping. |
