Anping County Anrun Stainless Steel Hardware Product Co., Ltd. >> Sintered Filter Made of Stainless Steel Wire Mesh

Sintered Filter Made of Stainless Steel Wire Mesh

Name: Sintered Filter Made of Stainless Steel Wire Mesh
Brand: china-manufacturer-directory.com
SKU: 677220762
Availability: InStock
Rating: 4.5 (84 reviews)

Supplier:	Anping County Anrun Stainless Steel Hardware Product Co., Ltd.
Price:	US $ 20/Piece
Min Order:	50/Piece
Quantity::
Trade Terms:	FOB,CFR,CIF

Product Specifications

Prod Model:	HRD-SSF
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Wire Diameter:	0.02mm-2mm
Size:	to Your Order
Material:	Stainless Steel Wire
Hole Shape:	Square
Application:	Gas Filtration
Type:	High Efficiency
Style:	Filter Disk

Product Description

Stainless steel sintered mesh for chemical fiber membrane

Description:

Stainless steel sintered mesh for chemical fiber membrane is through the special laminated compressed and vacuum sintering,it is a new filter material that with high mechanical strength and rigid structure.The layers of stainless steel sintered mesh crisscross each other, forming uniform filter group, high strength, good rigidity, stable aperture shape.

Advantage:

*1*Wear resistance.

*2*High temperature resistance.It can normally work under 600 degree long time.

*3*It can be clean and used repeatly.

*4*It can be welded process.

*5*Good rigidity and high strength.

Application:

Stainless steel sintered fiber mesh for chemical fiber membrane is suitable to filter and pure for all kinds of polymer melting body in chemical fiber membrane industry.

Model	Nominal Filter Rating(u)	Structure	Thickness (mm)	Air Permeability L/min/cm2	Bubble Pressure Mm H20	Weight Kg/m2	Porosity %
HX-10-1	1	100+400X2800+100+12X64+64X12	1.7	1.81	360-600	8.4 (five layers) 14.4 (six layers)	37%
HX-10-2	2	100+325X2300+100+12X64+64X12	1.7	2.35	300-590
HX-10-3	5	100+200X1400+100+12X64+64X12	1.7	2.42	260-550
HX-10-4	10	100+165X1400+100+12X64+64X12	1.7	3.00	220-500
HX-10-5	15	100+165X1200+100+12X64+64X12	1.7	3.41	200-480
HX-10-6	20	100+165X800+100+12X64+64X12	1.7	4.50	170-450
HX-10-7	25	100+165X600+100+12X64+64X12	1.7	6.12	150-410
HX-10-8	30	100+450+100+12X64+64X12	1.7	6.7	120-390
HX-10-9	40	100+325+100+12X64+64X12	1.7	6.86	100-350
HX-10-10	50	100+250+100+12X64+64X12	1.7	8.41	90-300
HX-10-11	75	100+200+100+12X64+64X12	1.7	8.7	80-250

Anping Hongruida Hardware Mesh Products Factory (Anping Country AnRun Stainless Steel Hardware Product Co., Ltd. ) is a specialized enterprise, having more than thirty sets of equipment for professionally producing wire mesh. With emphasizing on new-high technology, the factory has become the comprehensive enterprise for manufacturing both wire mesh and further processing products.

Our main products include stainless steel wire mesh, crimped wire mesh, wire mesh processed products, perforated metal, decorative wire mesh, sound barrier and other products. They are widely usedly in industries including chemical, mining, petroleum, farming, food, decorative material and construction.

Through several years' development, we have accumulated rich experience, possessesed great professional skill and created capability of new products development.

Hongruida as an ISO9001: 2000 certified manufacturer, has established stable relationship with customers in the USA, France, the U. K., South Korea and others.
