Product Specifications
| Prod Model: |
SJDSM-T |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Screw Diameter: |
50 |
| Screw Length And Diameter Ratio: |
25:1 |
| Frequency Converter: |
0.75kw×2 |
| Type: |
Pipe Extruder |
| Plastic Processed: |
PP |
| Product Type: |
Granulating Extruder |
| Feeding Mode: |
Multiple Feed |
| Assembly Structure: |
Integral Type Extruder |
| Screw: |
Multi-Screw |
| Automation: |
Automatic |
Product Description
The model is a tubing extrusion line. It is composed of extruder and die, Vacuum calibration and cooling unit, haul-off and rotary cutter or coiler, the entire machine's controls base with the control elements ergonomically adapted to permit easy operation. The machine is ideal for laboratory education and small production, the system is also suitable for extruding straws, refluxes and most diameter tubing and a wide range of industrial applications.
Technical parameters:
| Machine model | Mono-color straw machine
SJDSM-M | Dual-color straw machine
SJDSM-D | Tri-color straw machine
SJDSM-T | Four-color straw machine
SJDSM-F |
| Screw diameter | φ50 | φ50 | φ50 | φ50 |
| Screw length and diameter ratio | 25:1 | 25:1 | 25:1 | 25:1 |
| Motor | 7.5KW | 7.5KW+0.75KW×1 | 7.5KW+0.75KW×2 | 7.5KW+0.75KW×3 |
| Frequency converter | 0.75KW×2 | 0.75KW×2 | 0.75KW×2 | 0.75KW×2 |
| Yielding capacity | 25-35kg | 25-35kg | 25-35kg | 25-35kg |
| Product length | ≥5mm | ≥5mm | ≥5mm | ≥5mm |
| Product O.D. | 1.8mm-8mm
1.8mm-13mm | 1.8mm-8mm
1.8mm-13mm | 1.8mm-8mm
1.8mm-13mm | 1.8mm-8mm
1.8mm-13mm |
| Weight(T) | 0.9 | 1.0 | 1.2 | 1.3 |
