Product Specifications
| Prod Model: |
MIFARE card |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Dimensions: |
85.6X54 or Customized |
| Thickness: |
0.5mm, 0.76mm, 0.84mm |
| Materials: |
PVC, Pet, PETG, ABS Lamination |
| Card Surface: |
Matte/ Gloss Finish |
| Data Storage Time: |
10 Years |
| Chip: |
MIFARE Ultralight C, MIFARE Ultralight EV1 etc |
| Magnetic Option: |
300OE, 2750OE, 4000OE |
| Sample: |
Free |
| Delivery Time: |
7-8days |
| Printing: |
Logo Printing, Barcode Printing, Serial Number, etc |
| Function: |
Information |
| Material: |
PVC |
| Frequency: |
High Frequency |
| Type: |
MIFARE Card |
Product Description
Description :
- IC manufacturer: NXP founded by Philips
- Wafer die: MF 1 IC S50
- Unique serial number (4 Byte and 7 Byte)
- Function: Read/Write protect by password
- Memory: 1K-Byte EEPROM(16 sectors)
- Frequency: 13.56MHz
- RF protocol: ISO 14443A
MIFARE® Card Key Features:
- Card dimensions: 86 x 54mm
- Thickness: 0.84mm
- Material: PVC, PET
- Surface: lamination (gloss/mate)
- Chip: MIFARE Classic® 1K (NXP original)
- Frequency: 13.56MHz
- RF Protocol: ISO 14443A
- Data storage time: minimum 10 years
- Operating temperature: -20 to +60°C
- Stockage temperature: -20 to +65°C
- Package: 200pcs per Inner Box; 5000pcs per Carton, each Carton gross weight is 35kgs
Applications:
- Access control
- Membership Loyalty System
- Time attendance
- Hotel locks
- Payments
- Transportations
- NFC
Chip available:
MIFARE Cassic®, MIFARE® DESFire®, MIFARE Plus®, MIFARE Ultralight® etc
Optional produce:
Printing:
- Logo/Graphics/Photo
- Serial Number
- DOD Number
- Barcode printing
- Overlay Foil
- Signature Panel
- Name Personalisation
- Photo Personalisation
Magstripe:
- LoCo300
- HiCo2750
- Magstripe Encoding
Various:
- Hologram
- Security Printing
- Chip Encoing
A magnetic stripe card is a type of card capable of storing data by modifying the magnetism of tiny iron-based magnetic particles on a band of magnetic material on the card. The magnetic stripe, sometimes called swipe card or magstripe, is read by swiping past a magnetic reading head.According to the density of the magnetic particles in the stripe, magnetic stripe can be classified as HiCo(High Coercivity)magnetic stripe and LoCo(Low Coercivity) magnetic stripe.
| Dimension | ISO7810:CR80(85.5mm*54.5mm) or customized |
| Thickness | 0.84±0.02mm or customized |
| Material | PVC,PET,PET-G,Paper,ABS etc |
| Card Surface | Matte/ glossy finish |
| Working Frequency | 13.56 MHz |
| Reading Range | Depending on the design of the antenna of the reader |
| Housing | Lamination |
| Operating Temperature | -25 to +60°C |
| Storage Temperature | -40 to +70°C |
