Product Specifications
| Prod Model: |
ACP529 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Coating: |
PVDF or PE |
| Panel Thickness: |
3mm/4mm as Standard, and 2mm to 6mm Available. |
| Panel Length: |
2, 440mm (Standard), Customized to Any Length... |
| Panel Width: |
1000mm, 1, 220mm (Standard), 1250mm, 1275mm |
| Aluminum Skin Thickness: |
0.15mm to 0.50mm |
| Core: |
LDPE |
| Surface Finishing: |
Coating |
| Function: |
Fireproofing |
| Usage: |
External Wall |
Product Description
Solid color ACP aluminum composite material
1)ALUMASTER Aluminium composite panel is composed of a polyethylene core sandwiched between two sheets of aluminium. The surface of the panel is covered with a protective film. Outdoor ALUMASTER Aluminium composite panel is coated with PVDF coating on the surface,
While indoor ALUMASTER Aluminium composite panel is coated with PE coating.
2) Coated with extra-durable PE or PVDF resin, a composite structure which features excellent characteristics (fireproof, waterproof, heat-insulated, sound-insulated and resistance against corrosion, pollution and wear. )
3) Panel thickness:
A) 3mm/4mm (standard)
B) 2 - 6mm available upon request.
4) Aluminium skin thickness:
A) 0.50 x 0.50mm
B) 0.40 x 0.40mm
C) 0.30 x 0.30mm
D) 0.20 x 0.20mm
E) 0.15 x 0.15mm
F) 0.12 x 0.12mm
5) Width of aluminium composite panel:
A) 1000mm, 1, 220mm (standard), 1250mm, 1500mm, 1575mm.
B) Other widths available upon request.
5) Length of aluminium composite panel:
A) 2, 440mm (standard)
B) Up to 6, 000mm (recommended).
6) Features
1) Super peeling strength.
2) Excellent surface flatness and smoothness
3) Superior weather, corrosion and pollutant resistance
4) Even coating, various colors
5) Fireproof, excellent heat and sound insulation
6) Superior impact resistance
7) Lightweight and easy to process.
8) Easy to maintain.
Changshu Kaidi Decoration Material Co., Ltd., was established in 2002, specialized in producing aluminium composite panels and aluminium coils(natural plain, colour coated, embossed).We have two extra wide roll coating production lines and one standard ACP compositing production line, with international advanced technology.The annual capacity is 3, 000, 000 Sqms(ACPs) and 35, 000 Tons(Coils).
Our product of ALUMASTER aluminium composite panels gradually become an international brand.Kaidi has passed national standard GB/T 19001-2008 of Chinese Building Material Test and ISO9001-2008 Quality System Certificate and SGS as well as Fireproof Certificate.
Meanwhile, Kaidi has three coating lines including double coating and baking line with the maximum width catches 2000mm.The through put is 35, 000mt per year of different kinds of coated aluminum coils and embossed aluminum coils.
We are adhering to the "quality first, customers first, integrity-based" business purpose, through the high quality products, considerate service and professionals to establish long-term cooperation relations.Hope to be establish business relationship with all esteemed customers.
