Spring Cone Crusher (PYB/D/Z)

Name: Spring Cone Crusher (PYB/D/Z)
Brand: China-Manufacturer-Directory.com
SKU: 677597325
Availability: InStock
Rating: 4.3 (144 reviews)

Supplier:	Shanghai Changlei Machinery Complete Equipments Co., Ltd.
Price:	US $ 30000/Piece
Min Order:	1set
Quantity::
Trade Terms:	by Sea/land/air

Product Specifications

Prod Model:	PYB/PYD/PYZ series
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Mining Object:	Metallic and Non-Metallic Ore Excavator
Power:	145kw
Capacity:	50/120
Color:	Yellow, Red, White
Installation:	Under Engineer Guide
Feed Open:	400*1430
Weight:	18.8 T
Production Efficiency:	High
Crushing Ratio:	Big
Object:	Coal
Finished Surface:	Outer Surface Process
Drive:	Electric
Compressive Strength (',For Crushing):	250-300MPA
Crushing Degree:	Fine Grinding Machine
Type:	Cone Crusher
Crushing Style:	Extruding and Milling

Product Description

PYB\PYZ\PYD series Spring Cone Crusher
CHANGLEI HPC series cone crusher
Shanghai changlei Machinery Co., Ltd. is a leading stone crushing machine and screening equipments manufacturer in China, provides stone crushing machine and screening equipments for various industries such as mining, building material, metallurgy, environmental protection, transportation, chemistry, energy and so on.

Main Purpose of PYB\PYZ\PYD series Spring Cone Crusher:
Spring Cone Crusher of PYB\PYZ\PYD series is suited to crush medium to hard iron ore and rock. Ore crushing chamber depends on the type, standard applied for medium crushing; And the short head one for fine crushing.
Specifications of PYB\PYZ\PYD series Spring Cone Crusher.

Model	Max. feeding size( mm )	Discharging opening width(mm)	Capacity ( T / H )	Power (KW )	Weight(T) (not including motor)
PYD2200	100	5~15	120-340	280 -260	75.3
PYZ2200	230	10~30	200-580	280 -260	74.6
PYB2200	300	30-60	59-1000	280 -260	75
PYD1750	85	5~13	75-230	160	50.2
PYZ1750	185	10~30	115-320	160	50.3
PYB1750	215	25-50	280-480	160	50.3
PYD1200	50	3~15	18-105	110	25.3
PYZ1200	100	8~25	42-135	110	25
PYB2200	300	30-60	590-1000
PYB1200	145	20-50	110-168	110	24.7
PYD900	50	3~13	15-50	55	11.3
PYZ900	60	5~20	20-65	55	11.2
PYB900	115	15-50	50-90	55	11.2
PYD600	35	3~13	12~23	30	5.5
PYB600	65	12~25	40	30	5

Shanghai Changlei Machinery Complete Equipments Co., Ltd., is an international-type specialized business which specializes in manufacturing mining crushing machinery, sand processing equipment and industrial milling equipment. Integrated itself with the developing, producing and selling, we devote ourselves in offering our customers the crusher equipment with the highest quality and efficient.

Twenty years involving in this field, Changlei has a wide product coverage in our two producing factories, based in Jiangsu Province and Shanghai, and is also one of the biggest manufacturer for professional wear-resistant materials used in crushers in China. We do supply the wear-resistant components to many crusher equipment factories through which we win the trust and reputation from both our customers and other crushing manufacturers
