Water Filling Line Production Plant is one of advanced models which is our company combines international advanced self-filling process and technology developed specifically for mineral water, pure water and other non-gas beverage filling installation.
Feature of Water Filling Machine:
1 Direct connection technology between air conveyor and in-feeding starwheel is applied to replace in-feeding screw and conveying chain to ease bottle changing process with only to change few parts. Newly-designed bottle-separating grippers are assembled to starwheel.
2 We adopts Neck-hanging technology in bottle transportation. Instead of traditional starwheel, we use neck-hanging gripper to make bottle-size-changing easily , without equipment height adjustment ,only few parts need to be adjusted
3 Specially-designed rinser grippers which are made of stainless steel are firm and endurable, with no contact to screw part of the bottle to prevent second pollution.
4 High-speed, easily-cleaned filling valves with big flow volume are equipped with well CIP system and control system to rinse the equipment thoroughly.
5 splint of starwheel using twist descending way to simplify the process of bottle-size-changing. Only need to change arch board and starwheel, within ten minutes.
Parameters of Water Filling Bottling Machine:
Main technical parameters |
Model | RFC-W 14-12-5 | RFC-W16-16-5 | RFC-W24-24-8 | RFC-W32-32-8 | RFC-W40-40-10 | RFC-W50-50-15 | RFC-W60-60-15 | RFC-W72-72-18 |
Capacity | 3,000-5,000bph | 5,000-8,000bph | 10,000-12,000bph | 15,000bph | 18,000bph | 22,000-24,000bph | 28000-30,000bph | 36,000bph |
Suitable bottle | φ=50-110mm H=160 -310mm 200-2500ml PET bottles |
Power | 2.42kw | 3.12kw | 3.92kw | 3.92kw | 5.87kw | 7.87kw | 11.37kw | 11.37kw |
Dimension | 2360x1770x2700 | 2760x2060x2700 | 2800x2230x2700 | 3550x2650x2700 | 4700x3320x2700 | 5900x4150x2700 | 5770x5290x2700 | 6540x4900x2700 |
Weight | 2500kg | 3500kg | 3800kg | 4200kg | 5000kg | 8500kg | 11000kg | 13000kg |
