SSR Factory Supply 480V Single Phase DC to AC Solid State Relay 250A

Product Specifications

Prod Model:	SSR-250A
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe

Product Description

Product Description:
    solid-state relay (SSR) is an electronic switching device that switches states when an external voltage is applied along its n-type and p-type junctions. SSR has a small control signal that controls a larger load current or voltage. It consists of a sensor which responds to an appropriate input (control signal), a solid-state electronic switching device which switches power to the load circuitry, and some coupling mechanism to enable the control signal to activate this switch without mechanical parts. The relay may be designed to switch either AC or DC to the load. It serves the same function as an electromechanical relay, but has no moving parts.

Name: Solid state relay
Model: SSR-250A

Solid State Relay
Specifications
Input		3-32 VDC (fixed current ) 13mA 12V
Output		24-380VAC/90-480VA (10-75AMP)
Control Type		Zero Cross Trigger
Response time		ON<20ms/OFF<40ms
Voltage Withstand		Over 2.5Kvac/1MIN
Insulating strength		Over 50m/500VDC
Dimension		62.5*44.8*23.2mm
High strength ABS engineering plastics, gray case with LED indicator
Basic type	SSR-10DA	SSR-25DA	SSR-40DA	SSR-50DA	SSR-60DA	SSR-75DA
Hight voltage type		SSR-25DA-H	SSR-40DA-H	SSR-50DA-H	SSR-60DA-H	SSR-75DA-H
Input		Trimmer / 250K to 110V
Output		24-380VAC (10-40AMP)
Control Type		Phase control
Voltage Withstand		Over 2.5 Kvac/1MIN
Insulating strength		Over 50m/500VDC
Dimension		62.5*44.8*23.2mm
High strength ABS engineering plastics,gray case with LED indicator
Basic type	SSR-10VA		SSR-25VA		SSR-40VA
High voltage type
Input		80-250VAC
Output		24-380VAC/90-480VAC(10-75AMP)
Control Type		Zero Cross Trigger
Response time		ON<20ms/OFF<40ms
Voltage Withstand		Over 2.5 vac/1 MIN
Insulating strength		Over 50m/500VDC
Dimension		62.5X44.8X23.2mm
High strength ABS engineering plastics, gray case with LED indicator
Basic type	SSR-1 0AA	SSR-25AA		SSR-40AA		SSR-75AA
Hight voltage type		SSR-25AA-H		SSR-40AA-H		SSR-75AA-H
Input		3~32VDC 12mA@12V
Output		5~60VDC/5~200VDC(5~80AMP)
Insulating strength		Isolated by photocouple
Voltage withstand		ON 10ms/OFF 20ms
Control type		Over 2.5Kvac/1MIN
Response time		Over 50m/500VDC
Dimension		62.5X44.8X23.2mm
High strength ABS engineering plastics, gray case with LED indicator
Basic type	SSR-05DD	SSR-10DD	SSR-25DD	SSR-50DD	SSR-80DD
High voltage type		SSR-10DD-H	SSR-25DD-H	SSR-50DD-H	SSR-80DD-H
