Static Concrete Pump (HBTS30-10-37)

Name: Static Concrete Pump (HBTS30-10-37)
Brand: China-Manufacturer-Directory.com
SKU: 669633131
Availability: InStock
Rating: 4.4 (22 reviews)

Supplier:	Xuzhou Dajin Mining Technology Co., Ltd.
Price:	US $ 10000-30000/Piece
Min Order:	1/Piece
Quantity::
Trade Terms:	FOB,CFR,CIF

Product Specifications

Prod Model:	HBTS30-10-37
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Dimension(LWH):	4600mm1600mm1800mm
Weight:	3000kg
Hopper Capacity:	0.6
Feeding Height:	1100mm
Distribution Valve:	S Pipe Valve
Condition:	New
Certification:	ISO9001: 2000
Type:	Concrete Pump
Machining Process:	Hydraulic

Product Description

Features:
1. Simple and reliable system, hydraulic component can be used for a long time and maintain conveniently.
2. Hydraulic pipie is superior seamless steel tube: No leakage; Adopting unique buckle tube technology: No detonation and no leakage.
3. The adoption of the high pressure accumulator and its good buffer design make the swinging torque two times than the same model.
4. Electrical control tank is enclosed totally, which make control device can work in bad conditions.
2. The counterforce on specially designed "S" valve is received by hopper wall to assure the service life of goggle plate and cutting ring.
5. Electric control stepless variable adjust technology.
6. End hopper adopts reducing design: Reducing pressure release in delivery tube maximum, reducing the wearing life of S tube.
7. The side door can lift, operation and maintenance are very convenient. Side door with special technology can effectively reduce the operating noise.

Model	*HBTS25-8-37	**HBTS30-8-45	***HBTS30-10-37	***HBTS30-10-45	*****HBTS30-10-56R	****HBTS40-12-55
Dimension(LWH)	400016501600	400016501600	460016001800	435016501750	435016501750	435016501750
Hopper Capacity	0.6m³	0.6m³	0.6m³	0.6m³	0.6m³	0.6m³
Feeding Height	1100mm	1100mm	1100mm	1100mm	1100mm	1100mm
Weight	2500kg	2500kg	3000kg	3000kg	3200kg	3200kg
Theoretical delivery pressure	8Mpa	8Mpa	10Mpa	10Mpa	10Mpa	12Mpa
Theoretical concrete output	25m³/h	30m³/h	30m³/h	30m³/h	30m³/h	40m³/h
Hydraulic System	Open	Open	Open	Open	Open	Open
Power	37kw	45kw	37kw	45kw	56kw	55kw
Rotation speed	1480r/min	1480r/min	1480r/min	1480r/min	2200r/min	1480r/min
Distribution valve	S Pipe Valve	S Pipe Valve	S Pipe Valve	S Pipe Valve	S Pipe Valve	S Pipe Valve
Hydraulic Cylinder Diameter	φ90mm	φ90mm	φ90mm	φ100mm	φ90mm	φ100mm
Concrete Cylinder Diameter	φ140mm	φ140mm	φ140mm	φ160mm	φ140mm	φ160mm
High/Low Pressure Switch	/	/	/	/	/	/
Hydraulic Oil Tank Volume	120L	120L	120L	120L	120L	120L
Engine Type	Motor(380V)	Motor(380V)	Motor(380V)	Motor(380V)	Diesel(Deutz Weichai)	Motor(380V)
Max. Vertical Reach	80m	100m	120m	120m	100m	150m
Max. Horizontal Reach	240m	300m	360m	360m	300m	450m
Hydraulic Pump	Domestic	Handok	Handok	Handok	Handok	Handok
Hydraulic Elements	Imported	Imported	Imported	Imported	Imported	Imported
Concrete Slump	10~23cm	10~23cm	10~23cm	10~23cm	10~23cm	10~23cm
Max. Aggregate Diameter	30mm	30mm	30mm	30mm	30mm	30mm

Xuzhou Dajin Mining Technology Co., Ltd. is located in Xuzhou City, the largest Chinese machinery manufacturing bases. We have always been a leader in China construction machinery industry. At present, Xuzhou Dajin Mining Technology Co., Ltd. Ranks among Top 20 in the global construction machinery industry.

We are engaged in Concrete Machinery, Mine Machinery and Road Machinery including Concrete Pump, Mining Concrete Pump, Wet Concrete Sprayer, Road Roller and Motor Grader. The total asset is RMB30 million and the annual output reaches RMB50 million. We have done concrete machinery since last decade. The production is strictly according to ISO9000 standard. We have 12 production lines with the annual export turnover of over RMB20 million.

We believe that developing and manufacturing industry-leading products are always the top priority. Each year, we re-invest 5-7% of our sales revenue into the R&D, making it possible to expand our product line to concrete machinery. Besides constantly improving the quality, we are also committed to providing customers with all-round and efficient services.

"Customer is Our First Choice". We are confident that you will find the right products and satisfying services with our untiring efforts.
