Product Specifications
| Prod Model: |
As client's request or drawings |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Material: |
Steel Structure |
| Usage: |
Temporary Offices |
| Certification: |
CE |
Product Description
Features:
1. Cost saving and time saving
2. Light weight
3. Convenient and fast assembling and shipment
4. Environment friendly
5. Beautiful appearance, different color choice
Specifications:
1. The Prefabricated House which is easy to disassembly, assembly department and ship.
2. The framework is light steel system, all the parts are prefabricated.
3. The prefabricated house is wind-proof, and the maximum speed of the wind can be 120KM/H.
4. The prefab house is earthquake-proof, and the maximum grade is 8 degrees.
5. The foundation of the prefab house is easy to make or no needed.
6. The modular house can be recyclable, it can last for 20 years long, and no construction waste.
7. The prefab house is easy to install, a skilled worker can install 20SQM-30SQM one day.
8. The prefab house is easily customized. The houses can be designed accordingly to the clients' needs.
Materials Details:
1. Ground channel: C section steel, C80× 40× 15× 2mm
2. Column: Double C section steel, 2C80× 40× 15× 2mm welded
3. Beam for second floor: Steel frame 2 C80× 40×
4. Sub-beam for second floor: C section steel, 2 C80× 40× 15× 2mm
5. Purlin for roof: Angle steel L40× 4mm welded
6. Bracing for roof: Angle steel L40× 4mm
7. Bracing for aisle: C section steel, C80× 40× 15× 2mm welded
8. Bracing between the columns: Round steel bolt φ 8
9. Stairs: Steel stairs
10. Wall panel: V950 50mm thickness EPS or rock wool sandwich panel, steel plate: 0.3mm
11. Roof panel: V950 50mm thickness EPS or rock wool sandwich panel, steel plate: 0.3mm
12. Floor for second story: 16mm thickness plywood
13. Rain shelter: 0.45mm thickness corrugated steel sheet
14. Windows: PVC sliding windows
15. Door: Sandwich panel door or steel door
Qingdao Jiahexin Steel Co, . Ltd is located in Jiaozhou district, Qingdao city, with superior geographical position and convenient transportation. We are experienced and specialized in the production and steel structures, Steel welded fabrications, prefabricated house, T beams etc, it's business scope contains design, fabrication, logistics, trading etc.
We have advanced processing equipments, such as Auto Submerged Arc Welding Machines, CNC Cutting Machines, Straightening Machines, Shot Blasting Machines, Drilling Machines, Installing Machines, Assembling Machines and so on. Various steel structure products are galvanizing, painting, cold shaping, punching, drilling and cutting as the required.
We, Jiahexin Steel, an internationally advanced steel structure fabrication base which is renowned in both China and overseas market. Our products are marketed widely all over the country and exported to North American, Europe, Middle East, Oceania and Southeast Asia, etc. We have cooperated with many clients both from domestic and overseas, and has obtained consistently high praise based on good quality from our customers since it was set up. We sincerely welcome you to visit our company and contact us for long and kind cooperation.
"Jiahexin" is based on the trustworthiness cooperation and quality first always.
