Product Specifications
| Prod Model: |
Steel Structure |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Type: |
Steel Structure |
| Size: |
by Customized |
| Design: |
by Customized |
| Material: |
Steel Structure |
| Usage: |
Prefabricated Buildings |
| Certification: |
SGS |
| Customized: |
Customized |
Product Description
Materials:
1. Main structure: Welding H steel
2. Purlin: C section channel or Z section channel
3. Roof cladding: Sandwich panel or corrugated steel sheet with fiber glass wool coil
4. Wall cladding: Sandwich panel or corrugated steel sheet
5. Tie rod: Circular steel tube
6. Brace: Round bar
7. Column brace and transverse brace: Angle steel or H section steel or steel pipe
8. Knee brace: Angle steel
9. Roof ridge: Corrugated steel sheet
10. Wrapping cover: Color steel sheet
11. Roof gutter: Color steel sheet
12. Rainspout: PVC pipe
13. Connecting: High strength bolts
Features:
1) Materials: Q235 & Q345
2) Design according to customer's requirement.
3) Manufacture with high quality control.
4) Engineer helps to instruct installation.
5) Easy to assemble and dismantle.
6) Main materials: H beam/C purlin/Z purlin/sandwich panel/ corrugated steel sheet
7) Life: Over 35 years
8) Nice appearance, easy to maintenance.
Common uses:
Temporary construction houses of field work as the ablution unit, road, railway, building, etc.
City municipal, commercial and other temporary housing. Such as: Temporary offices, conference rooms, headquarters, lodging house and temporary store, temporary schools, temporary hospitals, temporary parking area, temporary exhibition gallery, temporary power distribution room, temporary maintenance, temporary service station, etc.
And also it is used for temporary housing of military logistic, temporary space of disaster relief, sterile laboratories, isolation rooms, transforming communications room, and temporary tourist and temporary travel district casual villa, vacation house etc.
Features:
Reliable Structure
Water proof
Weather proof
Heat insulation and preservation characteristics.
Fire proof
Elegant outlook
Architectural effect.
Convenient for transportation.
Multi assemble / Dis-Mantle type.
Technical Specification:
Standard Terms used: MT × NT× NH= Width × Length × Height, T =1150mm, H=1000mm,
Standard width(mT): M≥ 2, T =1150mm
Standard Length(nT): N≥ 2, T =1150mm
Partition as per client's requirements.
Well, certainly, the cons of the metal storage buildings are much less than its pros. It can be said that metal for storage buildings is a near-perfect material and that is why it is immensely popular in our times.
1. | Main steel frame : | Steel Welded H Section or hot rolled H section (specification Q235 , Q345 ) for columns and beams |
| | Secondary frame : | hot dip galvanized C purlin , steel bracing , tie bar , knee brace , edge cover etc. |
| 2. | Roof panel : | EPS sandwich panel , glass fiber sandwich panel , rock wool sandwich panel , and Pu sandwich panel or steel sheet |
| Wall panel : | Sandwich Panel or Corrugated Steel Sheet |
| Tie Rod: | Circular Steel Tube |
| Brace: | Round Bar |
| Column & Transverse Brace: | Angle Steel or H Section Steel or Steel Pipe |
| Knee Brace: | Angle Steel |
| Roof Gutter: | Color Steel Sheet |
| Rainspout: | PVC Pipe |
| 3. | Door: | Sliding Sandwich Panel Door or rolling Metal Door |
| Windows: | PVC/Aluminum Alloy Window |
| Connecting: | post feet bolts, intensive bolt , intensive bolt |
| 4. | Packing: | according to the pack list made by our engineer |
| 5. | Drawing: | We can make the design and quotation according to your require or y |
Foshan Shengbang Steel Structure Co., Ltd. (for short "SBS") is a fast developing enterprises integrating marketing, design, development, manufacturing and construction. It has been approved and certified by international ISO9001: 2008 quality management system, and SGS factory system. We have trained many highly qualified marketing and technical personnel as well on-site construction team during recent years' fast development. Being customer demand-oriented, SBS provides a full range of services with rational, scientific and effective solutions, as a practical, progressive, innovative & solidarity company.
Our company prefabricated house is a new type environmental friendly product that adopts steel structure as frames, employs various plates and panels as surrounding protection system, uses high strength bolts as component connection. The prefabricated house is mainly used as modular house, office, cleaning workshop, cold storage room, wide span workshop, warehouse, exhibition hall, stadiums, hangars, steel-structure supermarkets, high-rise steel constructions, logistics center, container house and so on. Our house has been sold well to Middle East, Africa, Southeast Asia, South America and other more than 30 countries and areas.
Foshan Shengbang Steel Structure Co., Ltd. Possesses professional large-scale steel structure production equipments and the automatic spraying production line, so we can satisfy the different customers demand. We takes "build your future" as mission and takes company growth as premise. The company has trained many high quality marketing personnel, professional technician and construction workers. We take the customers' demand as the guidances, then provide reasonable, scientific and effective solution for customers. We regard practical growth, innovation and group solidarity as our company spirit, so that we can offer all-round service to customers.
Foshan Shengbang Steel Structure Co., Ltd. Will cooperate sincerely with the customers and build better future under the principle of win-win cooperation.
