Product Specifications
| Prod Model: |
DB-25A |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Model: |
Dcs-50A |
| Volume Of Bag: |
20,25, 50kg |
| Speed: |
300 Bags Per Hour |
| Height Of Machine: |
1.5m |
| Main Power: |
5.5kw |
| Power Of Belt Conveyor: |
0.37kw |
| Length Of Conveyor: |
2m |
| Sealing Method: |
Heat Sealing; Sewing |
| Threads Of Sewing: |
2 Threads; 4 Threads |
| Warranty: |
One Year |
| Automatic Grade: |
Automatic |
| Applicable Industry: |
Machinery & Hardware |
| Driven Type: |
Electric |
| Material Type: |
Grain |
| Packaging Material: |
Film |
| Application: |
Pellets,Grain,Rice |
| Packaging Type: |
Bags |
Product Description
1. APPLICATION RANGE
The sysem is applied to quantitative automatic weighing, filling, kneading, accumulating weigh and times, stitching andconveying with manual assistant for powder material in the flour factory or other industry.
2. FEATUPES
2.1 Take three speeds feeding to guarantee the precision at min weight and the speed at max weight.
2.2 The head of bag stitching machine, conveyor, and hot sealing machine can rise and fall. And at the same time, the system is applied to sealing and convey with max and min bags.
2.3 There is shock-absorbing device in weighing system; It could avoid the shock of other devices through floor and tube to affect the weighing sustem.
2.4 There is good seal in system, and it has dust catcher and aspirator.
2.5 The is guide groves in conveyor roller and guide bars in conveyor belts to avoid excutsion and cracks.
3. FUNCTION
3.1 There is detecting device in system.
3.2 Processes function of automatic modifying drop height.
3.3 Processes function of self-test, error pilot and fault code indication. 3.4 With the serial interfere to communicate the computer.
3.5 With five-figure password to control the accumulator in system. 3.6 Pre-set filling number in system.
4. MAIN TECH-PARAMETERS
| Model | Packing range (kg/bag) | Power | Error
(F.S) | Speed
(bags/min) | Air supply
(MPa) | Division Value (g) |
| DB-5A | 1-5 | AC
220V/50Hz | 0.1%-0.2% | ≥ 6 | 0.4-0.8 | 1-5 |
| DB-10A | 1-10 | 1-10 |
| DB-25A | 5-15 | 5-10 |
| DB-50A | 5-25 | 5-10 |
| DB-100A | 15-50 | 10-20 |
