Product Specifications
Prod Model: |
FM-C500 |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Model: |
FM-R500 |
Width Of Mother Roll: |
300-500mm |
Width Of Finished Roll: |
300-500mm |
Diameter Of Mother Roll: |
350mm |
Diameter Of Finished Roll: |
150mm(Maximum) |
Core Of Mother Roll: |
3'' |
Core Of Finished Roll: |
3'' 2'' 1.5'' |
Speed: |
0-1000 Meters/Min |
Power: |
5.5 Kw |
Weight: |
950 Kg |
Product Description
Stretch Film Rewinding Machine for PVC
Introduction:
Our FM-C500 Five Shafts Rewinding Machine specially used for rewinding the industrial stretch film/cling film. It can rewind the large diameter rolls into many same width small diameter finished rolls. The appearance of finished goods could be looked better with high automotive ability and easy operation, hence, the working efficiency could be improved a lot with less man power.
Features:
1. Five-axis loop rewinding, high efficiency;
2. PLC+HIM+Inverter control system, high degree of automation;
3. Paper tube bucket automatic alarm without paper tube, automatic stop chuck without paper tube. Full of use-friendly design;
Specification:
Model--------------------------------FM-C500
Width of Mother Roll-----------------500mm
Width of Finished Roll---------------300-500mm
Diameter of Mother Roll--------------400mm
Diameter of Finished Roll------------120mm(Maximum)
Core of Mother Roll------------------3''
Core of Finished Roll----------------3'' 2'' 1.5''
Speed--------------------------------600 meters/min
Power--------------------------------5.5 Kw
Weight-------------------------------750 Kg
Dimension----------------------------1200*1500*1450mm
