Supplier: | Shenzhen Retop LED Display Co., Ltd. |
---|---|
Price: | US $ 1/Piece |
Min Order: | 5/Piece |
Quantity:: | |
Trade Terms: | FOB |
![]() |
Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
---|---|
Display Type: | LED Video Display |
Tube Chip Color: | Full Color |
IP Rating: | IP65 |
Application: | Advertising |
Display Function: | Video Display |
Scanning Mode: | Static Scan |
Certification: | CCC |
Pixel Configuration: | 8r8g6b |
Pixel Pitch: | 76.2mm |
Pixel Density: | 172DOT/M&Sup2 |
Average Power Consumption: | 102W |
Resolution | 76.2mm | |||||||||||||||||||||||||||||||||||||||
LAMP | LED Type | DIP | ||||||||||||||||||||||||||||||||||||||
Wave length | R: 620-622 nm | |||||||||||||||||||||||||||||||||||||||
G: 522-524 nm | ||||||||||||||||||||||||||||||||||||||||
B: 466-468 nm | ||||||||||||||||||||||||||||||||||||||||
STRIP | Pixel configuration | Retop | Cree | |||||||||||||||||||||||||||||||||||||
8R8G6B | 6R6G4B | |||||||||||||||||||||||||||||||||||||||
LED driving method | Static | |||||||||||||||||||||||||||||||||||||||
Pixels | 16 | * | 1 | (W*H) | ||||||||||||||||||||||||||||||||||||
Pixel pitch | 76.2 | mm | ||||||||||||||||||||||||||||||||||||||
Led strip size | 1219 | mm | * | 19 | mm | * | 23 | mm | (W*H*D) | |||||||||||||||||||||||||||||||
MODULE | Led strip | 1 | * | 16 | (W*H) | |||||||||||||||||||||||||||||||||||
Pixels | 20 | * | 16 | (W*H) | ||||||||||||||||||||||||||||||||||||
Module area | 1.86 | m 2 | ||||||||||||||||||||||||||||||||||||||
Module size | 1524 | mm | * | 1219 | mm | * | 140 | mm | (W*H*D) | |||||||||||||||||||||||||||||||
Net weight | 30 | kg | ||||||||||||||||||||||||||||||||||||||
Power | AC220/110 ± 10%, 47~63Hz | |||||||||||||||||||||||||||||||||||||||
Water proof | IP65(strip) | |||||||||||||||||||||||||||||||||||||||
Serviceability | Rear service | |||||||||||||||||||||||||||||||||||||||
DISPLAY | Max. power consumption | R | ≤ | 290 | W/m 2 | C | ≤ | 270 | W/m 2 | |||||||||||||||||||||||||||||||
Avg. power consumption | ≤ | 102 | W/m 2 | ≤ | 95 | W/m 2 | ||||||||||||||||||||||||||||||||||
Max. current (208V 60Hz) | ≤ | 1.47 | A/m 2 | ≤ | 1.37 | A/m 2 | ||||||||||||||||||||||||||||||||||
Hor. viewing angle(min 50% brightness) | 140° | |||||||||||||||||||||||||||||||||||||||
Vert. viewing angle(min 50% brightness) | 70° | |||||||||||||||||||||||||||||||||||||||
Brightness | ≥ 6000 cd/m 2 | |||||||||||||||||||||||||||||||||||||||
Pixel density | 172 | /m 2 | ||||||||||||||||||||||||||||||||||||||
Power factor | > 0.9 | |||||||||||||||||||||||||||||||||||||||
Certifications | UL, CE, ETL, ROSH, CCC | |||||||||||||||||||||||||||||||||||||||
Contrast ratio | 1500: 1 | |||||||||||||||||||||||||||||||||||||||
Operating temperature | -20º C to +60º C | |||||||||||||||||||||||||||||||||||||||
Operating humidity | 20% to 90% | |||||||||||||||||||||||||||||||||||||||
Lifetime (50% brightness) | 100, 000 hours | |||||||||||||||||||||||||||||||||||||||
Processing | 16 bit | |||||||||||||||||||||||||||||||||||||||
Colors | 281 trillion | |||||||||||||||||||||||||||||||||||||||
Refresh rate | ≥ 4200 Hz | |||||||||||||||||||||||||||||||||||||||
Frame rate | 60 fps | |||||||||||||||||||||||||||||||||||||||
Brightness level | Manual 100 levels, automatically 16 levels. |
