Product Specifications
| Prod Model: |
S-F8 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Business Type: |
Manufacture & Export |
| Technique: |
3D |
| Camera: |
2 PCS |
| Target Disk: |
4 PCS |
| Column Height: |
Adjustable |
| Certification: |
CE~@~ISO |
| Update Method: |
by Internet |
Product Description
Model No. 3D wheel alignment SP-G7
Software Features
Basic Functions:
Parameters measurement such as camber, Caster, Kingpin inclination, Toe-in & Toe-out, Set back, Thrust angle
Extension Functions:
1. Axis deviation measurement
2. Wheel deviation measurement,
3. Animation
4. Single-wheel measurement
5. The vehicle lifts measurement
6. Steering wheel align function
7. Alignment platform levelness testing function
8. Engine bay adjustment
9. Lock Toe measurement
10. Toe curvature measurement
11. Ride height measurement
12. Air suspension vehicles alignment software(proprietary software)
13. Rolling Radius Measurement
14. Scrub Radius Measurement
15. Wheel distance measurement
16. Axis distance measurement
Features:
1. 3D dynamic measurement based on auto body is not influenced by lift platform, meets auto real value well.
2. Measurement system equipped with double digital cameras and four target plate, supplying revolutionary measurement mode.
3. There is no electronic component, so the wheel alignment will not have a component failure problem.
4. Equipment Calibration: Once calibration before ex-factory, workable immediately after installation, no need for periodic calibration
5. Measurement progress: No need to compensate for steel ring, the precise eccentric compensation will be just once pulling or pushing the car back and forth
6. Software system Easy to operate, complete conventional basic parameters within two minutes, significantly faster than conventional aligners
7. Easily maintenance, download and upgrade freely for the model data
8. Compile customers' name, license plate and other information for checkout easily
|
|
avaible operation languange |
|
1 |
Chinese |
|
2 |
spanish |
|
3 |
Hebrew |
|
4 |
Dutch |
|
5 |
Russia |
|
6 |
Turkey |
|
7 |
Czech |
|
8 |
Japanese |
|
9 |
korean |
|
10 |
thailand |
|
11 |
English |
|
12 |
Portugue |
Yantai Haide Science And Technology Co., Ltd. is a joint-stock enterprise specialized in manufacturing and marketing four-wheel alignments, lifts, tyre changer, wheel balaner and other auto inspection instruments. Since our foundation, our company has received a reputation for innovation and visionary leadership in the application of the newest technologies to automotive car service equipment.
Our company has covered a ground area of 43, 500 square meters, with the complete building area of 25, 000 square meters including two manufacturing bases. The newly introduced equipment, together with advanced surface-processing production lines, has provided the guarantee for its superb quality. We are the first national company that has established own training base.
Our products include 3 series: wheel alignments and car lifts, tyre changer & wheel balancer. There are 3 types of wheel alignments, such as 3D, CCD and laser wheel alignments, and more than 40 types of car lifts, including two post lifts and four post lifts and scissor lifts. Now our company is a primary supplier for major car manufacturers and 4S shops. We have more than 300 members, 20 of whom are engineers with master's or doctor's degree working in the Technology Research Center. More than 80 salesmen have established a good national selling system including 20 provincial branches. Good supervision makes our after-sales service more perfect.
Our company is a modern and competitive company with a leading position in car service equipment field around the world.
