Product Specifications
| Prod Model: |
SGS-2040AHD Automatic Surface Grinder |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Automatic Grade: |
Automatic |
| Precision: |
High Precision |
| Type: |
Surface Grinding Machine |
| Controlling Mode: |
Artificial |
| Processing Object: |
Curve |
Product Description
SGS-2040AHD Automatic Surface Grinder
20" X 40" working capacity
3-axis automatic movement with incremental downfeed, electronic auto-crossfeed, and hydraulic powered table movement
Precision hand scrapped turcite V and flat table ways and double V column ways for smooth and long lasting precision
High column design with 23" spindle center to table for extra clearance under the wheel and rapid elevation motor for quick/easy positioning
Centralized automatic one-shot lubrication system provides lubrication to all points
Safety 24V control circuit power
|
Specs |
|
SPEC\MODEL |
SGS-1020AHD |
SGS-1230AHD |
SGS-1640AHD |
SGS-2040AHD |
|
Table Travel: |
20.5" |
31.75" |
43" |
43" |
|
Saddle Travel: |
10.5" |
13.5" |
17.75" |
20.25" |
|
Working Capacity: |
10"x20" |
12"x30" |
16"x40" |
19.67"x40″ |
|
T-Slot: |
1 x 9/16" |
1 x 9/16" |
1 x 9/16" |
3 x 9/16" |
|
Spindle Motor: |
2 HP |
5 HP |
7.5 HP |
10 HP |
|
Spindle Speed: |
3580 RPM |
1750 RPM |
1750 RPM |
1750 RPM |
|
Grinding Wheel: |
8"x1/2"x1-1/4" |
14"x1-1/4"x5" |
14"x2"x5" |
16"x2″x5″ |
|
Vertical Graduation: |
0.0005″ |
0.0005" |
0.00025" |
0.0001" |
|
Vertical Revolution: |
0.1000" |
0.1000" |
0.0500" |
0.0200" |
|
Auto Downfeed Increment: |
0.0001″ 10 Steps |
0.0001″ 10 Steps |
0.0001″ 10 Steps |
0.0002" 10 Steps |
|
Spindle To Table: |
19" |
23" |
23" |
23" |
|
Net Weight: |
2900 LBS |
4400 LBS |
6260 LBS |
11,000 LBS |
|
Gross Weight: |
3100 LBS |
5060 LBS |
6500 LBS |
11,900 LBS |
|
Accesories |
|
|
|
|
Standard |
Optional |
|
|
|
Grinding Wheel |
S |
|
|
|
|
Wheel Flange |
S |
|
|
|
|
Wheel Balancing Base |
S |
|
|
|
|
Wheel Balancing Arbor |
S |
|
|
|
|
Diamond Table Dresser Base & Tip |
S |
|
|
|
|
Leveling Bolts & Pads |
S |
|
|
|
|
Work Light |
S |
|
|
|
|
Toolbox w/ Tools |
S |
|
|
|
|
DRO System |
|
O |
|
|
|
20×40 Interloc w/ Control |
|
O |
|
|
|
20×40 Fine Pole Electric Chuck & Control |
|
O |
|
|
|
Static Wheel Balancing Base |
|
O |
|
|
|
Extra Wheel Flange |
|
O |
|
|
|
Rustlick Coolant (1 Gal, Mixes 1:30) |
|
O |
|
|
