SGS-2448AHD Automatic Surface Grinder
24X48 working capacity
3 axis automatic movement
Precision turcite ways
Double-vee column cross traverse
NC Z-axis w/ servo motor and ball screw
Hydraulic table & electronic crossfeed
Automatic lubricator & rapid elevation
Automatic Surface Grinder
|
Specs Automatic Surface Grinder |
|
SPEC\MODEL |
SGS-2460AHD |
SGS-2448AHD |
SGS-2480AHD |
|
Longitudinal Travel: |
65" |
51 1/4" |
82 2/3" |
|
Cross Feed Travel: |
25.6" |
24 1/4" |
24 1/4" |
|
Table Size: |
23 1/2" x 59" |
23 1/2" x 47 1/4″ |
23 1/2" x 78 3/4″ |
|
T-Slot: |
3″ x 9/16" |
3″ x 9/16" |
3″ x 9/16" |
|
Spindle Motor: |
10 HP |
15 HP |
15 HP |
|
Wheel Speed: |
1750 RPM |
1150 RPM |
1150 RPM |
|
Grinding Wheel: |
16" x 2" x 5" |
20" x 2" x 8" |
20" x 2" x 8" |
|
Vertical Graduation: |
0.0001" |
0.0001" |
0.0001" |
|
Vertical Revolution: |
0.0200" |
0.0200" |
0.0200" |
|
Auto Downfeed Increment: |
0.0001" to 0.0333″ Per Pass |
0.0001" to 0.0333″ Per Pass |
0.0001" to 0.0333″ Per Pass |
|
Spindle To Table: |
33" |
33" |
33" |
|
Table Speed: |
16-80 ft/min |
16-80 ft/min |
16-80 ft/min |
|
Net weight: |
13,200 LBS |
15,000 LBS |
25,200 LBS |
|
Accesories |
|
|
Standard |
Optional |
|
|
Grinding Wheel |
S |
|
|
|
Wheel Flange |
S |
|
|
|
Wheel Balancing Base |
S |
|
|
|
Wheel Balancing Arbor |
S |
|
|
|
Diamond Table Dresser Base & Tip |
S |
|
|
|
Magnetic Separator & Paper Filter Coolant |
S |
|
|
|
24″ x 48″ Electro-Magnetic Chuck & Control |
S |
|
|
|
Hydraulic Overhead Parallel Dresser |
S |
|
|
|
NC Z-Axis Controller |
S |
|
|
|
Toolbox w/ Tools |
S |
|
|
|
DRO System |
|
O |
|
|
Static Wheel Balancer |
|
O |
|
|
Extra Wheel Flange |
|
O |
|
|
Rustlick Coolant (1 Gal, Mixes 1:30) |
|
O |
|
